PT2522C-4
4 left in stock
GRS PT2522C-4, 66mm (3.5in / 3-1/2in) Planar Tweeter with Back Cup 4 Ohm, 68mm x 90mm Faceplate
CA$73.92Each
- PT2522C-4
- GRS
GRS PT2522C-4, 66mm (3.5in / 3-1/2in) Planar Tweeter with Back Cup 4 Ohm, 68mm x 90mm Faceplate
With a low mass diaphragm and powerful motor, the GRS PT2522C-4 planar sealed back tweeter delivers high efficiency output with excellent transient response. The low profile sealed back allows this tweeter to be installed easily into conventional speakers without the need for a separate sub-enclosure. Remarkably smooth frequency response gives the PT2522C-4 an incredibly natural but dynamic sound.
Key Features
- Extremely low mass diaphragm provides excellent transient response and accuracy
- Large diaphragm produces high efficiency and wide bandwidth
- Multiple neodymium magnets in push pull arrangement for incredible control and low distortion
- Remarkably flat response even at 30 degrees off axis
- Linear impedance simplifies crossover design
- Shallow mounting depth for use in low profile designs
- Custom mounting faceplate available
Key Specs:
- Tweeter Type: Planar Magnetic
- Power Handling (RMS): 20 Watts
- Power Handling (MAX): 40 Watts
- Impedance: 4Ω
- Frequency Response: 1800 - 20,000 Hz
- Sensitivity: 94dB 2.83V/1m
- Diaphragm Material: Polyethylene Naphthalate
| FILENAME | ACTION |
|---|---|
| pt2522c-4.pdf | Download |
