Product Specifications | |
---|---|
Manufacturer | BLIESMA |
Midrange Type | Aluminum Magnesium Dome Midrange Open Back |
Cone / Dome Diameter | 137mm |
Impedance | 6 ohms |
Power Handling (RMS) | W |
Frequency Response | 180 - 2800 Hz |
Sensitivity | 94.5 dB |
Features :
• 137 mm AlMg alloy dome with variable thickness for higher first breakup mode
• Extremely low moving mass for better transient response and higher efficiency
• Fully saturated neodymium motor with copper sleeve for low non linear and modulation distortion
• Single-layer ribbon CCAW voice coil for lower inductance • Underhung voice coil wound on titanium former
• 137 mm voice coil for low thermal compression
• Ring magnet system with large rear opening reduces backside reflections and improves dipole operation
• Natural silk surround and cotton spider from Dr. Kurt Müller GmbH & Co. for higher midrange resolution
• Surround hidden in basket rim allows significant reduction of mounting diameter
• Thick aluminium powder coated basket
• Gold plated wire terminals
• Recommended frequency range 180 Hz - 2,8 kHz
