Dayton Audio AMT3-4, 33cm2 Air Motion Transformer Tweeter 4 Ohm, 130mm Faceplate
Product Specifications | |
---|---|
Manufacturer | DAYTON AUDIO |
Tweeter Type | Air Motion Ribbon Tweeter |
Ribbon Surface | 33cm2 |
Impedance | 4 ohms |
Power Handling (RMS) | 25 W |
Frequency Response | 1900 - 18000 Hz |
Sensitivity | 93 dB |
Dayton Audio AMT3-4 Air Motion Transformer Tweeter 4 Ohm The Dayton Audio AMT3-4's generous radiating area extends response from lower frequencies into the upper midrange, making the transducer great for use as a wideband "mid-tweeter" in a 2-way design with larger woofers, or as a midrange in a 3-way design. The robust metal faceplate adds the distinctive feel of quality, while the sealed rear chamber design eliminates the need for a separate enclosure chamber. Dayton Audio AMT (Air Motion Transformer) tweeters use groundbreaking transducer technology from the original Heil Air Motion Transformer to provide ultra-clean, detailed, and dynamic treble output. The pleated ribbon diaphragm of an AMT provides a large acoustic radiating area condensed into a compact chassis, for extremely high output and improved power handling.
FILENAME | ACTION |
---|---|
amt34-1.pdf | Download |
