Dayton Audio SA25 25W Subwoofer Plate Amplifier
|Power Output @ 8ohms/4ohms
|S/N ratio @ rated power
|Input sensitivity @ 100Hz low level
|Input sensitivity @ 100Hz high level
|Variable low pass X-over frequencies
|Dimensions W x H x D
||159mm x 159mm x 64mm
|Cutout W x H
||134mm x 134mm
This ultra-compact 25-watt subwoofer amplifier offers the perfect amount of power for any small subwoofer system. It delivers a real 25 watts RMS of power, which is not an exaggerated figure like found in most typical multimedia systems. With a solid 25 watts, it has enough oomph to reach 100 dB with many drivers. Measuring only 6-1/4" square, the 25-watt amp will fit in even the smallest enclosures.
• Measured power output: 15 watts RMS into 8 ohms @ 0.1% THD, 25 watts RMS into 4 ohms @ 0.2% THD • Signal to noise ratio: 90 dB (A-weighted) • Power requirement: 120 VAC • Dimensions: 6-5/16" W x 6-5/16" H x 2-9/16" D • Enclosure cutout: 5-1/4" W x 5-1/4" H.
