Dayton Audio SPA500DSP 500W Subwoofer Plate Amplifier with DSP
CA$583.16Each
Choose another model
  • Choose another model
  • Dayton Audio APA150 150W Power Amplifier CA$308.69Each
  • HYPEX REMOTE CA$18.20Each
  • Lepai LP-168HA CA$55.83Each
  • SA-100 CA$177.16Each
  • SA-25 CA$90.09Each
  • SA-70 CA$123.39Each
  • SA1000 Subwoofer Amplifier CA$824.38Each
  • SPA1000 CA$719.41Each
  • SPA250 CA$278.41Each
  • SPA500 CA$535.44Each
  • SPA250DSP CA$367.50Each
  • BSA-200 CA$384.15Each
  • FA501 CA$681.10Each
  • FUSION REMOTE KIT CA$43.61Each
  • DTA-2.1BT2 CA$138.58Each
  • FA251 CA$483.12Each
  • DTA-100LF CA$179.83Each
  • SPA100-D CA$153.26Each
  • SPA300-D CA$238.11Each
  • FUSION OLED DISPLAY CA$99.78Each
Choose another model
  • Choose another model
  • HYPEX REMOTE CA$18.20Each
  • PWR-ICE125 CA$693.00Each
  • PWR-ICE250 CA$924.00Each
  • MINIDSP2X4HD CA$369.60Each
  • IRREMOTE V2 CA$10.01Each
  • SPA250DSP CA$367.50Each
  • DSP-408 CA$250.62Each
  • DSP-BT4.0 CA$75.44Each
  • DDRC-24 CA$693.00Each
  • WI-DG CA$120.12Each
  • FA122 CA$573.56Each
  • FA123 CA$681.10Each
  • FA253 CA$878.28Each
  • FA501 CA$681.10Each
  • FUSION REMOTE KIT CA$43.61Each
  • SHD CA$1,792.70Each
  • SHDSTUDIO CA$1,480.50Each
  • PPA800DSP CA$637.84Each
  • BAX-1 CA$4,395.00Each
  • CDSP8X12 V2 CA$820.82Each
  • CDSP8X12DL CA$1,401.40Each
  • CI8-120DSP CA$4,549.00Each
  • CI8-150DSP CA$5,999.00Each
  • SHDPOWER CA$2,093.00Each
  • FA503 CA$1,075.44Each
  • FA251 CA$483.12Each
  • FA252 CA$769.90Each
  • FA502 CA$969.53Each
  • CI16-60DSP CA$3,899.00Each
  • DSP-NRC CA$50.49Each
  • HARMONY DSP 8X12 CA$1,547.00Each
  • FLEX CA$727.65Each
  • FLEXBAL CA$822.15Each
  • FLEXDIGI CA$727.65Each
  • FLEX EIGHT CA$774.90Each
  • FLEX HT CA$850.50Each
  • FLEX HTX CA$1,398.60Each
Product Specifications
Manufacturer DAYTON AUDIO
Summary
Specifications: SPA500DSP
Power Output @ 4ohms 500W
THD 0.1%
S/N ratio @ rated power 97.9dB
Input sensitivity @ 80Hz low level 280mV
Input impedance 12Kohms
Variable low pass X-over frequencies 20-200Hz 12 or 24db
Weight 4.3lbs/1.96kgs
Dimensions W x H 184mm x 260mm
Cutout W x H 159mm x 235mm
AC Voltage 115V / 230V
Volume Variable
Frequency Variable 30-200Hz
Variable Bass EQ DSP
Certifications CE

Dayton Audio SPA500DSP 500W Subwoofer Plate Amplifier with DSP Dayton Audio's SPA500DSP true 500 watt digital switching plate amplifier features advanced signal processing control that every audio enthusiast wants. This power and flexibility is accessible via PC-GUI software and our innovative single-knob LCD control panel. For retrofit and enclosure designs with no amplifier cutout an optional amplifier mounting frame is available for this amplifier. Specifications: • Power output: 500 watts RMS into 4 ohms, THD+N <0.1% • Signal to noise ratio: 97.9 dB (A-weighted) • Input sensitivity (RCA): 320 mV - 1.4 V • Input sensitivity (XLR): 630 mV - 2.7 V • Power requirements: 110~120/220~240 VAC selectable, 50/60 Hz • Amplifier dimensions: 10.25" H x 7.25" W x 2.125" D; Amplifier cutout: 9.25" H x 6.25" W.
