Hypex, FusionAmp FA251, 250 Wrms Ncore Amplifier Module with DSP. Now with FIR!
CA$483.12Each
Choose another model
  • Choose another model
  • Dayton Audio APA150 150W Power Amplifier CA$308.69Each
  • HYPEX REMOTE CA$18.20Each
  • Lepai LP-168HA CA$55.83Each
  • SA-100 CA$177.16Each
  • SA-25 CA$90.09Each
  • SA-70 CA$123.39Each
  • SA1000 Subwoofer Amplifier CA$824.38Each
  • SPA1000 CA$719.41Each
  • SPA250 CA$278.41Each
  • SPA500 CA$535.44Each
  • SPA250DSP CA$367.50Each
  • SPA500DSP CA$583.16Each
  • BSA-200 CA$384.15Each
  • FA501 CA$681.10Each
  • FUSION REMOTE KIT CA$43.61Each
  • DTA-2.1BT2 CA$138.58Each
  • DTA-100LF CA$179.83Each
  • SPA100-D CA$153.26Each
  • SPA300-D CA$238.11Each
  • FUSION OLED DISPLAY CA$99.78Each
Choose another model
  • Choose another model
  • HYPEX REMOTE CA$18.20Each
  • PWR-ICE125 CA$693.00Each
  • PWR-ICE250 CA$924.00Each
  • MINIDSP2X4HD CA$369.60Each
  • IRREMOTE V2 CA$10.01Each
  • SPA250DSP CA$367.50Each
  • SPA500DSP CA$583.16Each
  • DSP-408 CA$250.62Each
  • DSP-BT4.0 CA$75.44Each
  • DDRC-24 CA$693.00Each
  • WI-DG CA$120.12Each
  • FA122 CA$573.56Each
  • FA123 CA$681.10Each
  • FA253 CA$878.28Each
  • FA501 CA$681.10Each
  • FUSION REMOTE KIT CA$43.61Each
  • SHD CA$1,792.70Each
  • SHDSTUDIO CA$1,480.50Each
  • PPA800DSP CA$637.84Each
  • BAX-1 CA$4,395.00Each
  • CDSP8X12 V2 CA$820.82Each
  • CDSP8X12DL CA$1,401.40Each
  • CI8-120DSP CA$4,549.00Each
  • CI8-150DSP CA$5,999.00Each
  • SHDPOWER CA$2,093.00Each
  • FA503 CA$1,075.44Each
  • FA252 CA$769.90Each
  • FA502 CA$969.53Each
  • CI16-60DSP CA$3,899.00Each
  • DSP-NRC CA$50.49Each
  • HARMONY DSP 8X12 CA$1,547.00Each
  • FLEX CA$727.65Each
  • FLEXBAL CA$822.15Each
  • FLEXDIGI CA$727.65Each
  • FLEX EIGHT CA$774.90Each
  • FLEX HT CA$850.50Each
  • FLEX HTX CA$1,398.60Each
Choose another model
  • Choose another model
  • HYPEX REMOTE CA$18.20Each
  • PWR-ICE125 CA$693.00Each
  • PWR-ICE250 CA$924.00Each
  • LP40PA CA$51.57Each
  • FA122 CA$573.56Each
  • FA123 CA$681.10Each
  • FA253 CA$878.28Each
  • FA501 CA$681.10Each
  • FUSION REMOTE KIT CA$43.61Each
  • PPA800DSP CA$637.84Each
  • LP210PA CA$109.15Each
  • FA503 CA$1,075.44Each
  • FA252 CA$769.90Each
  • FA502 CA$969.53Each
  • SBA302BT CA$209.49Each
  • FUSION OLED DISPLAY CA$99.78Each



Product Specifications
Manufacturer HYPEX ELECTRONICS
Summary Hypex FusionAmp FA251Mono 250W The FusionAmp is our new plate amplifier range, powered by our new mains powered NCORE modules. There are one, two and three way systems available, each with balanced and unbalanced analog inputs. The one-way models also have a high level analog input. The multi-way models have a digital input instead. This FusionAmp can be the basis of e.g. a powerful active subwoofer or a one-way monitor. The FA251 has one powerful 250 Wrms Ncore® amplifier. The FusionAmp is designed to be mounted in vertical or horizontal position. The FusionAmp may be tilted 45° in both direction as depicted. Vent holes should not be covered and free convection should not be impeded. To protect your valuable drivers, the DSP does not contain a filter out of the box. A filter needs to be configured and uploaded using Hypex Filter design (HFD) software before the FusionAmp will produce an output signal. Please refer to the online HFD manual for more information. Since the FusionAmp’s DSP does not contain a filter by default, you need to get started with HFD. This free software can be downloaded from the Hypex website. You can start getting acquainted with the software, even without a Hypex product connected. An elaborate guide on how to design the filters can be found on the Hypex website. The Fusion Amp must be mounted into the speaker cabinet with 8 or 10 screws, not included. Hypex recommends Phillips head screws, 4.3 x 25.4 mm. Fusion-Amps can also be operated with remote control for volume control and source selection. Our well known Hypex Remote Control can be used for this. To use a remote, you will need the new IR-receiver kit, also available as a separate module via the pull-down menu. Specs
Mains voltage input 100-120Vac / 200-240Vac ±10%
Power (4Ω) 1x 250Wrms
Channels 1 channel / 1 way
Dimensions mm 280*120*55mm
Weight 725gr
Connections
  • Analogue balanced XLR in and through
  • Analogue unbalanced RCA input
  • High level input
  • USB 2.0 configuration interface
Features
  • 15 biquads per amplifier
  • Three selectable presets for filters
  • Source selection
  • Signal detect
  • Auto shutdown
  • Clip protect
  • Thermal protect
  • Filter protection

Meet the family The Fusion Amp family consists of the following models: FusionAmp One-Way models: FA251, 1x250W FA501, 1x500W FusionAmp Two-Way models: FA122, 2x125W FA252, 2x250W FA502, 2x500W FusionAmp Three-Way models: FA123, 2x125W + 100W Tweeter FA253, 2x250W + 100W Tweeter FA503, 2x500W + 100W Tweeter

What is included in the box:

  • The FA251
  • A printed copy of the user guide
  • Speaker connection cables
  • High-level input connector



AC Cable NOT Included!

FILENAME ACTION
Fusion-Manual.pdf Download
