PTT1.3T04-HAG-10

Out of stock
Purifi PTT1.3T04-HAG-10, 33mm (1.3in / 1-1/4in) Aluminium Dome Waveguide Tweeter, 4ohm, 147mm Faceplate.
CA$1,036.80Each

Purifi PTT1.3T04-HAG-10, 33mm (1.3in / 1-1/4in) Aluminium Dome Waveguide Tweeter, 4ohm, 147mm Faceplate.



Product Specifications
Manufacturer PURIFI AUDIO
Speaker Type Aluminium Dome Waveguide Tweeter
Dome Diameter 33mm
Impedance 4 ohms
Power Handling (RMS)  W
Frequency Response 640 - 30000 Hz
Sensitivity 96 dB
Faceplate Diameter 147mm



This tweeter is based on PTT1.3T04-HAG-01 delivering the signature crystal-clear sound PURIFI is known for, but featuring a 147mm waveguide optimised for directivity control matching 5" - 6.5" midranges or woofers (e.g. SPK16 reference design) whilst maintaining a super wide dispersion.



The PTT1.3T04-HAG-10 features:

  • Wide-dispersion Waveguide with cooptimized, integrated Coherer
  • Negligible Force Factor Modulation (FFM) and Surround Radiation Distortion (SRD)
  • Extremely Low Magnetic Hysteresis Distortion (MHD)
  • High Sensitivity, high linear volume displacement
  • Designed and manufactured in Denmark
FILENAME ACTION
ptt13t04hag10.pdf Download
