Scan-Speak Revelator 32W/4878T00, 320mm (12in) Paper Cone Subwoofer, with 75mm Voice Coil, 4ohm.
| Product Specifications | |
|---|---|
| Manufacturer | SCAN-SPEAK |
| Speaker Type | Paper Cone Subwoofer |
| Nominal Diameter | 32cm |
| Impedance | 4 ohms |
| Power Handling (RMS) | 800 W |
| Frequency Response | 18 Hz |
| Sensitivity | 90 dB |
| Voice Coil Diameter | 75mm |
The 32W/4878T00 is the most powerful sub woofer designed by Scan-speak to this date, with its large 3” voice coil, extreme linear excursion and low resonance frequency is it perfect to reproduce the deepest frequencies. It features a brand new type of paper-sandwich cone with a special foam filling technology (patented) that gives the cone very high stiffness and relative low weight. The motor system has heavy duty copper sleeves for reducing eddy currents and minimizing self-induction.
- Paper sandwich cone with Patented foam filling
- Extreme linear excursion (+/-14 mm)
- Patented Symmetrical Drive motor
- 3" Voice coil, Titanium former and paper reinforced
- Spider with balanced woven in tinsel leads
- Stiff and strong die cast aluminium chassis
| FILENAME | ACTION |
|---|---|
| 32w4878t00.pdf | Download |
