Dimensions des Haut-parleurs

*Veuillez SVP mettre votre téléphone à l'horizontal afin de voir le tableau.*
ATC Overall Ø Cutout Ø FP Thickness Bolt Pattern Ø Connector + Type -
SM75-150 190mm 154mm 22mm 4x M6 @ 172mm 4mm Mini Banana
SM75-150S 190mm 154mm 22mm 4x M6 @ 172mm 4mm Mini Banana
SB75-234SC 240mm 212mm 13mm 8x M5 @ 226mm Push Push
SB75-314 316mm 286mm 14mm 8x M6 @ 300mm Push Push
SB75-375SC 390mm 348mm 15mm 8x M6 @ 370mm Push Push
SB100-375SC 390mm 348mm 15mm 8x M6 @ 370mm Push Push
ATD Overall Ø Cutout Ø FP Thickness Bolt Pattern Ø Connector + Type -
14W2608AGTI 139x139mm 123mm 5mm 4x M4 @ 145mm .250" .250"
14W2608AGTI-BM 139x139mm 123mm 5mm 4x M4 @ 145mm .250" .250"
18W5408AGTI 184x184mm 166mm 5mm 4x M5 @ 191mm .250" .250"
18W5408AGTI-BM 183x204mm 165mm 5.1mm 6x M4 @ 192mm .250" .250"
AIRBORNE Overall Ø Cutout Ø FP Thickness Bolt Pattern Ø Connector + Type -
UR74B4-13T 74mm 50mm * 4.3mm 3x M4 @ 61mm .110" .110"
HR104B8-15T 105mm 78mm * 4mm 5x M5 @ 89.5mm .205" .110"
HR124B8-10L 124.5mm 94.5mm 3mm 4x M4 @ 115mm .110" .110"
FR148B6-11L 148mm 126mm 5.5mm 5x M5 @ 136mm .205" .110"
FR148B6-17L 148mm 126mm 5.5mm 5x M5 @ 136mm .205" .110"
FR148B6-18L 148mm 126mm 5.5mm 5x M5 @ 136mm .205" .110"
FR148B8-10M 148mm 126mm 5.5mm 5x M5 @ 136mm .205" .110"
FR173B6-16L 173mm 146.5mm 6mm 6x M4 @ 163mm .205" .110"
FR173B8-10M 173mm 146.5mm 6mm 6x M4 @ 163mm .205" .110"
FR213B8-10M 213mm 186mm 9mm 6x M6 @ 197mm .205" .110"

AUDAX Overall Ø Cutout Ø FP Thickness Bolt Pattern Ø Connector + Type -
HP080G0 92mm 72.5mm 5mm 4x M4 @ 84mm .205" .110"
AUDIENCE Overall Ø Cutout Ø FP Thickness Bolt Pattern Ø Connector + Type -
A3 83x92mm 70mm 4mm 4x M3 @ 111mm .205" .110"
AUDIOTECHNOLOGY Overall Ø Cutout Ø FP Thickness Bolt Pattern Ø Connector + Type -
4H521306 155mm 131mm 8mm 6x M5 @ 142mm .250" .250"
5H521506 180mm 156mm 8mm 6x M5 @ .250" .250"
6H521706 205mm 177mm 8mm 6x M5 @ 189mm .250" .250"
8I522008 230mm 201mm 8mm 8x M5 @ .250" .250"
10A772510 275mm 240mm 10mm 8x M5 @ .250" .250"
12B772510 335mm 297mm 10mm 8x M6 @ .250" .250"
15E1022510 410mm 367mm 13mm 8x M6 @ .250" .250"
AURASOUND Overall Ø Cutout Ø FP Thickness Bolt Pattern Ø Connector + Type -
NSW1-205-8A 49mm 36mm 9mm 4x M3 @ 43mm .205" .110"
NSW2-326-8A 60mm 47mm 12.5mm 4x M3 @ 54mm .205" .110"
NS3-193-8A 88.5x88.5mm 78mm * 1mm 4x M4 @ 93mm .205" .110"
NS4-255-4D 105x105mm 100mm * 1mm 4x M4 @ 115mm .205" .110"
NS4-255-4D1 105x105mm 100mm * 1mm 4x M4 @ 115mm .205" .110"
NS4-255-8D 105x105mm 100mm * 1mm 4x M4 @ 115mm .205" .110"
NS4-255-8D1 105x105mm 100mm * 1mm 4x M4 @ 115mm .205" .110"
NS10-513-4A 261.2mm 225.7mm 10mm 8x M5 @ 244.5mm PUSH PUSH
NS12-513-4A 309.7mm 279.3mm 10mm 8x M5 @ 293.6mm PUSH PUSH
NS10-794-4A 268.2mm 233mm 10.8mm 8x M5 @ 244mm SCREW SCREW
NS12-794-4A 317mm 280mm 11.5mm 8x M5 @ 293.9mm SCREW SCREW
NS15-992-4A 393.4mm 352mm 12.8mm 8x M6 @ 369.8mm SCREW SCREW
NS18-992-4A 477mm 427mm 14.9mm 8x M6 @ 446.8mm SCREW SCREW
CSS Overall Ø Cutout Ø FP Thickness Bolt Pattern Ø Connector + Type -
ERT26 74mm 43mm * 4mm 3x M4 @ 62mm .110" .110"
RT1 125mm 52x78mm 4mm 6x M4 @ 113mm 10-24 10-24
LAR1 80x168mm 52x146mm 4mm 10x M4 @ 68x156mm 10-24 10-24
EL70 124mm 102mm 6mm 4x M4 @ 112mm .205" .205"
FR125S 126mm 96mm 4mm 4x M4 @ 115mm .205" .110"
WR125ST 109x126mm 96mm 4mm 4x M4 @ 115mm .205" .110"
SDX7 173mm 146mm 5.5mm 6x M4 @ 163mm .250" .250"
EL166 165mm 143mm 4.2mm 8x M4 @ 155.5mm .205" .205"
SDX10 274mm 229mm 16mm 8x M6 @ 249mm Binding Post Binding Post
TRIO12 314mm 276mm 14mm 8x M5 @ 297mm .250" .250"
APR10 257mm 230mm 12mm 8x M5 @ 246mm None None
APR12 311mm 279mm 13.5mm 8x M5 @ 279mm None None
APR15 390mm 350mm 17mm 8x M5 @ 371mm None None
DAYTON AUDIO Overall Ø Cutout Ø FP Thickness Bolt Pattern Ø Connector + Type -
ND16FA-6 32.5mm 32.5mm 9mm None .110" .110"
ND20FA-6 45mm 33mm 2mm None .110" .110"
ND20FB-4 35.7mm 35.7mm None 4x M3 @ 43mm .110" .110"
ND28F-6 65mm 44mm 3mm 4x M3 @ 55.7mm .110" .110"
DC25T-8 99.5mm 70mm * 3mm 4x M4 @ 90mm .205" .110"
DC25TS-8 99.5mm 68mm * 3mm 4x M4 @ 90mm .205" .110"
DC28F-8 110mm 74mm * 3mm 3x M4 @ 100mm .205" .205"
DC28FS-8 110mm 78mm * 3mm 3x M4 @ 100mm .205" .205"
DC28FT-8 85x110mm 74mm * 3mm 3x M4 @ 100mm .205" .205"
DC28FST-8 85x110mm 78mm * 3mm 3x M4 @ 100mm .205" .205"
RS28A-4 104.8mm 74mm * 3.4mm 4x M4 @ 90.4mm .250" .250"
RS28AS-4 104.8mm 71mm * 3.4mm 4x M4 @ 90.4mm .250" .250"
RS28F-4 104.8mm 74mm * 3.4mm 4x M4 @ 90.4mm .250" .250"
DAYTON AUDIO Overall Ø Cutout Ø FP Thickness Bolt Pattern Ø Connector + Type -
PT2C-8 88x178mm 64x156mm 2.5mm 6x M4 @ 78x120mm .205" .110"
DC50F-8 145.3mm 104.4mm 3.2mm 3x M4 @ 133mm .110" .110"
RS52AN-8 130mm 100mm 3mm 6x M5 @ 114mm .205" .110"
RS75-4 72mm 54mm 4mm 4x M3 @ 64mm .205" .110"
RS75T-8 58.8x72mm 54mm 4mm 4x M3 @ 64mm .250" .250"
RS100-4 98mm 78mm 3mm 6x M4 @ 90mm .250" .250"
RS100-8 98mm 78mm 3mm 6x M4 @ 90mm .250" .250"
RS100T-8 84x98mm 78mm 3mm 6x M4 @ 90mm .250" .250"
RS125-4 125.5mm 94mm 4mm 6x M4 @ 112.6mm .250" .250"
RS125-8 125.5mm 94mm 4mm 6x M4 @ 112.6mm .250" .250"
RS125T-8 103x125.5mm 94mm 4mm 6x M4 @ 112.6mm .250" .250"
RS150-4 150mm 122mm 4mm 6x M4 @ 138mm .205" .110"
RS150-8 150mm 122mm 4mm 6x M4 @ 138mm .205" .110"
RS150T-8 130x150mm 122mm 4mm 4x M4 @ 138mm .205" .110"
RS180-4 180.5mm 146mm 5mm 6x M5 @ 168.5mm .250" .250"
RS180-8 180.5mm 146mm 5mm 6x M5 @ 168.5mm .250" .250"
RS225-4 223mm 184mm 5mm 6x M5 @ 209mm PUSH PUSH
RS225-8 223mm 184mm 5mm 6x M5 @ 209mm .250" .250"
RS270-8 272mm 236mm 5.5mm 6x M5 @ 238mm .250" .250"
RS270S-8 272mm 236mm 5.5mm 6x M5 @ 238mm .250" .250"
ND90-4 93mm 76.5mm 1mm 4x M4 @ 88.4mm .205" .110"
ND90-8 93mm 76.5mm 1mm 4x M4 @ 88.4mm .205" .110"
ND105-4 105mm 93mm 1mm 4x M4 @ 108.5mm .205" .110"
ND105-8 105mm 93mm 1mm 4x M4 @ 108.5mm .205" .110"
ND140-4 138mm 120mm 1mm 4x M4 @ 138mm .205" .110"
ND140-8 138mm 120mm 1mm 4x M4 @ 138mm .205" .110"
DA115-8 115.6mm 93mm 3mm 4x M4 @ 107mm .205" .205"
DAYTON AUDIO Overall Ø Cutout Ø FP Thickness Bolt Pattern Ø Connector + Type -
DC130AS-8 134mm 120mm 6.8mm 4x M5 @ 137.6mm .205" .205"
DC130BS-4 145mm 120mm 6.2mm 4x M5 @ 133.2mm .205" .205"
DC130BS-8 145mm 120mm 6.2mm 4x M5 @ 133.2mm .205" .205"
DA135-8 135mm 112mm 3.2mm 4x M4 @ 126mm .205" .205"
DC160-8 165mm 145mm 8.4mm 4x M5 @ 156.5mm .205" .205"
DC160S-4 165mm 145mm 8.4mm 4x M5 @ 156.5mm .205" .205"
DC160S-8 165mm 145mm 8.4mm 4x M5 @ 156.5mm .205" .205"
DA175-8 175.6mm 144mm 3.5mm 5x M4 @ 166mm .205" .205"
DC200-8 205mm 183mm 9mm 4x M5 @ 195mm .205" .205"
DA215-8 216mm 180mm 3.5mm 5x M4 @ 206.4mm .205" & .110" .205" & .110"
DC250-8 256mm 234mm 10mm 4x M5 @ 245.5mm .205" .205"
DA270-8 270mm 227mm 3.8mm 5x M5 @ 260mm .205" & .110" .205" & .110"
DC300-8 306.5mm 280mm 11.3mm 8x M5 @ 291.5mm .205" .205"
DC380-8 385mm 349mm 14mm 8x M6 @ 365mm .205" .205"
ST210-8 209mm 177mm 3.3mm 8x M5 @ 200mm .205" .205"
ST255-8 256mm 230mm 4.1mm 8x M6 @ 245.4mm .205" .205"
ST305-8 305.5mm 279mm 3.9mm 8x M6 @ 294.3mm .205" .205"
ST385-8 384.8mm 350mm 4.8mm 8x M6 @ 369.8mm .205" .205"
RSS210HF-4 213mm 185mm 8mm 6x M4 @ 197mm PUSH PUSH
RSS265HF-4 266mm 235mm 9.5mm 6x M5 @ 248mm PUSH PUSH
RSS265HO-4 266mm 235mm 9.5mm 6x M5 @ 248mm PUSH PUSH
RSS315HF-4 314mm 282mm 9.6mm 8x M5 @ 295mm PUSH PUSH
RSS315HF-8 314mm 282mm 9.6mm 8x M5 @ 295mm PUSH PUSH
RSS315HO-4 314mm 282mm 9.6mm 8x M5 @ 295mm PUSH PUSH
RSS315HO-44 314mm 282mm 9.6mm 8x M5 @ 295mm PUSH PUSH
RSS390HF-4 388.4mm 356mm 10.5mm 8x M6 @ 368mm PUSH PUSH
RSS390HO-4 388.4mm 356mm 10.5mm 8x M6 @ 368mm PUSH PUSH
DAYTON AUDIO Overall Ø Cutout Ø FP Thickness Bolt Pattern Ø Connector + Type -
IB385-8 385mm 350mm 4.75mm 8x M6 @ 369.9mm PUSH PUSH
DCS205-4 208mm 180mm 10mm 8x M5 @ 198mm PUSH PUSH
DCS255-4 258mm 232mm 12.5mm 8x M5 @ 248mm PUSH PUSH
DCS305-4 306mm 275mm 12mm 8x M6 @ 294.5mm PUSH PUSH
DCS380-4 385mm 349mm 14mm 8x M6 @ 365mm .250" .250"
DCS450-4 454mm 417mm 14mm 8x M6 @ 442mm .250" .250"
TIT280C-4 279.4mm 238mm 15mm 8x M6 @ 258mm PUSH PUSH
TIT320C-4 317.5mm 280mm 15mm 8x M6 @ 298mm PUSH PUSH
TIT400C-4 393.7mm 356mm 15mm 8x M6 @ 373.4mm PUSH PUSH
SD215-88 216mm 180mm 3.5mm 5x M4 @ 206.4mm .205" .205"
SD270-88 270mm 227mm 3.8mm 5x M5 @ 260mm .205" .205"
SD315-88 314mm 272m 3.5mm 5x M5 @ 304mm .205" .205"
DVC310-88 311.2mm 281mm 4.1mm 8x M6 @ 295.4mm PUSH PUSH
DVC385-88 385mm 350mm 4.75mm 8x M6 @ 369.9mm PUSH PUSH
QT210-4 209mm 177mm 3.3mm 8x M5 @ 199.9mm .205" .205"
QT255-4 256.2mm 230mm 4.2mm 8x M6 @ 245.4mm .205" .205"
QT305-4 305.5mm 279mm 3.85mm 8x M6 @ 294.3mm .205" .205"
SD215-PR 216mm 180mm 3.5mm 5x M4 @ 206.4mm None None
NS210-44 210mm 187mm 12mm 8x M5 @ 197mm PUSH PUSH
NS270-44 272.2mm 239mm 12mm 8x M6 @ 257.5mm PUSH PUSH
NS310-44 315mm 282mm 13mm 8x M6 @ 297mm PUSH PUSH
SD270-PR 270mm 227mm 3.8mm 5x M5 @ 260mm None None
SD315-PR 314mm 272m 3.5mm 5x M5 @ 304mm None None
DVC310-PR 311.2mm 281mm 4.1mm 8x M6 @ 295.4mm None None
DVC385-PR 385mm 350mm 4.75mm 8x M6 @ 369.9mm None None
NS270-PR 210mm 187mm 10mm 8x M5 @ 197mm None None
NS310-PR 315mm 282mm 10mm 8x M6 @ 297mm None None
NS390-PR 387.5mm 354mm 10mm 8x M6 @ 374mm None None
E.J. JORDAN Overall Ø Cutout Ø FP Thickness Bolt Pattern Ø Connector + Type -
JXR6HD 90x77mm 64mm 5.7mm 4x M4 @ 80x68mm .205" & .110" .205" & .110"
JX92S 140mm 113mm 4mm 4x M5 @ 132mm .205" & .110" .205" & .110"
JX125NG 185mm 145mm Rounded 6x M5 @ 170mm .205" .110"
JX150NG 230mm 188mm Rounded 6x M5 @ 213mm .205" .110"
EMS Overall Ø Cutout Ø FP Thickness Bolt Pattern Ø Connector + Type -
LB7 174mm 146mm 6.5mm 4x M4 @ 161mm .250" .250"
LB8EX 235mm 188mm 7mm 4x M5 @ 217mm .250" .250"
LB12 / LB12EX 314mm 282mm 8mm 8x M5 @ 296mm Binding post Binding post
B15EX 402mm 360mm 12mm 8x M6 @ 382mm Binding post Binding post
ETON Overall Ø Cutout Ø FP Thickness Bolt Pattern Ø Connector + Type -
19SD1 110mm 75mm * 2.7mm 4x M4 @ 98mm .110" .110"
25SD1 110mm 75mm * 2.7mm 4x M4 @ 98mm .110" .110"
26HD1/A8 90mm 63mm 5.2mm 4x M4 @ 75mm .205" .205"
ER4 110x110mm 83x94mm 3mm 4x M4 @ 90x94mm 4mm Mini Banana
4-200/A8/25 116mm 96mm 5mm 6x M4 @ 108mm .205" .110"
4-202/C8/25 116mm 96mm 5mm 6x M4 @ 108mm .205" .110"
5-300/A8/25 145mm 118mm 6mm 6x M4 @ 137mm .205" .110"
ETON Overall Ø Cutout Ø FP Thickness Bolt Pattern Ø Connector + Type -
5-302/C8/25 145mm 118mm 6mm 6x M4 @ 137mm .205" .110"
5-880/25 157mm 128mm 7.5mm 8x M4 @ 144.5mm .205" .110"
7-200/A8/32 175mm 152mm 6mm 6x M5 @ 165mm .205" .110"
7-202/C8/32 175mm 152mm 6mm 6x M5 @ 165mm .205" .110"
7-300/A8/32 175mm 152mm 6mm 6x M5 @ 165mm .205" .110"
ETON Overall Ø Cutout Ø FP Thickness Bolt Pattern Ø Connector + Type -
7-302/C8/32 175mm 152mm 6mm 6x M5 @ 165mm .205" .110"
7-360/37 186mm 160mm 7.7mm 8x M4 @ 164.5mm .205" .110"
7-372/32H 184mm 150mm 7mm 6x M5 @ 159.5mm .205" .110"
7-375/32 175mm 152mm 6mm 6x M5 @ 165mm .205" .110"
8-200/A8/37 223mm 194mm 6mm 6x M5 @ 212mm .205" .110"
8-202/C8/37 223mm 194mm 6mm 6x M5 @ 212mm .205" .110"
8-472/32H 222.5mm 184mm 8mm 6x M5 @ 198.5mm .205" .110"
8-800/37 223mm 203mm 8.5mm 8x M4 @ 216mm .205" .110"
11-581/50 281mm 244mm 8mm 6x M5 @ 266mm .205" .110"
12-680/62 332mm 291mm 8.5mm 8x M6 @ 315mm Binding Post Binding Post
FOSTEX Overall Ø Cutout Ø FP Thickness Bolt Pattern Ø Connector + Type -
FT7RP 76x88mm 50x73mm 3mm 4x M4 @ 64x76mm .250" .250"
FT207D 95mm * 79mm 3mm 3x M4 @ 83mm .205" .205"
FT28D 90x78mm 70mm 6mm 4x M3 @ 65x53mm .205" .205"
FT33RP 108mm   18mm 4x M4 @ 94mm 10-24 10-24
FT48D 128mm 103mm 8mm 4x M5 @ 115mm .205" .205"
FT17H 87mm 62.5mm* 3mm 4x M4 @ 76mm .110" .110"
FT96H 68x68mm 60mm 6mm 4x M4 @ 82mm SCREW SCREW
T90A 60mm   74.1mm* None SCREW SCREW
T925A 82mm   91mm* None SCREW SCREW
T500AmkII 99mm   108.5mm None SCREW SCREW
T900A 82mm   81.8mm None SCREW SCREW
FE83EN 83x83mm 70mm 3.8mm 4x M4 @ 86mm .205" .205"
FE103EN 107x107mm 92mm 2.6mm 4x M4 @ 115mm .205" .205"
FE108ES 128mm 102mm 7.5mm 8x M5 @ 115mm .205" .205"
FW108N 128mm 102mm 7.5mm 8x M5 @ 115mm .205" .205"
F120A 123x123mm 103mm 6mm 4x M4 @ 126mm .205" .205"
FOSTEX Overall Ø Cutout Ø FP Thickness Bolt Pattern Ø Connector + Type -
FE126EN 117x117mm 102.2mm 3.1mm 4x M5 @ 126mm .205" .205"
FW137 155mm 121mm 9.8mm 6x M4 @ 135mm .205" .205"
FE166EN 166x166mm 143.4mm 3.8mm 4x M5 @ 174mm .205" .205"
FW167 186mm 143mm 10mm 6x M4 @ 160mm .205" .205"
FE168ES 190mm 155mm 11mm 8x M6 @ 174mm .205" .205"
FW168N 190mm 155mm 11mm 8x M6 @ 174mm .205" .205"
FW168FP 190mm 155mm 11mm 8x M6 @ 174mm .205" .205"
F200A 194x194mm 182mm 6.5mm 4x M6 @ 198mm PUSH PUSH
FE206EN 208x208mm 182mm 5.5mm 4x M5 @ 220mm .205" .205"
FE208ES 230mm 185mm 11.1mm 8x M6 @ 213mm .205" .205"
FW208N 230mm 185mm 11.1mm 8x M6 @ 213mm .205" .205"
W300A2 312mm 278mm 15mm 4x M7 @ 294mm PUSH PUSH
W400A-HR 395mm 350mm 18mm 8x M8 @ 372.5mm Binding Post Binding Post
FW305 312mm 278mm 15mm 4x M7 @ 294mm PUSH PUSH
FW405N 395mm 350mm 18mm 8x M8 @ 372.5mm Binding Post Binding Post
FW800HS 800mm 748mm 25mm 8x M8 @ 770mm PUSH PUSH
FOUNTEK Overall Ø Cutout Ø FP Thickness Bolt Pattern Ø Connector + Type -
NEOCD1.0 100mm 55x68mm 6mm 4x M4 @ 61x61mm 10-24 10-24
NEOCD3.0 110mm 62x90mm 6mm 4x M5 @ 78x52mm 10-24 10-24
NEOCD2.0 85x165mm 62x143mm 6mm 4x M5 @ 70x149mm 10-24 10-24
NEOCD3.5H 98x110mm 69x86mm 4mm 4x M3 @ 70x85mm 10-24 10-24
NEOPRO5i 115x190mm 95x170mm 5mm 6x M5 @ 100x175mm Binding Post Binding Post
FR88-EX 88.4mm 73mm 4.3mm 4x M4 @ 81mm .205" .110"
FR89-EX 88.4mm 73mm 4.3mm 4x M4 @ 81mm .205" .110"
FR89-EX04 88.4mm 73mm 4.3mm 4x M4 @ 81mm .205" .110"
FR135EX 145.5mm 115mm 4.2mm 4x M4 @ 136mm .205" .110"
FOUNTEK Overall Ø Cutout Ø FP Thickness Bolt Pattern Ø Connector + Type -
FW146 145.5mm 115mm 4.2mm 4x M4 @ 136mm .205" .110"
FW168 180mm 146mm 4.2mm 4x M4 @ 168mm .205" .110"
HI-VI RESEARCH Overall Ø Cutout Ø FP Thickness Bolt Pattern Ø Connector + Type -
K1 116mm 84mm 4mm 3x M4 @ 102mm .205" .205"
Q1R 116mm 79mm 3.7mm 6x M4 @ 101.5mm .110" .110"
SS1II 102mm 74mm 3.5mm 6x M4 @ 102mm .110" .110"
SD1.1A 116mm 84mm 4mm 6x M4 @ 102mm .205" .205"
T20-8 52mm 36mm 3mm 4x M4 @ 44mm .110" .110"
TN25 54.5x54.5mm 42mm 4mm 4x M4 x 58mm .110" .110"
TN28 46.5mm Top Mount     Wire Wire
X1 116mm 86mm 3.5mm 8x M4 x 102mm .110" .110"
X1R 116mm 74mm 3.5mm 8x M4 x 102mm .110" .110"
R1L 110mm 79mm 2mm 3x M4 @ 100mm .110" .110"
RT1.3 88x102mm 50x78mm 4mm 4x M4 @ 76x90mm .110" .110"
RT1.3M 61x106mm 50x78mm 4mm 4x M4 @ 42x96mm .110" .110"
RT1.3WE 120mm 89.5mm 2.5mm 4x M4 @ 108mm .110" .110"
RT1II 100x130mm 54x89mm 6mm 6x M4 @ 89x114mm .110" .110"
RT1CA 120mm 89.5mm 2.5mm 4x M4 @ 108mm .110" .110"
RT1EP 150x107mm 74mm 3.5mm 4x M4 @ 95mm .110" .110"
RT2II 160x186mm 68.5x161mm 6mm 4x M4 @ 145x166mm .205" .110"
RT2CA 176mm 65x157mm 3.5mm 6x M4 @ 162mm .205" .110"
RT2EA 105x176mm 65x157mm 4mm 6x M4 see drawing .205" .110"
RT2HA 168.5x182.5mm 156x158mm 3mm 6x M4 @ 171x158mm .205" .110"
RT2M 91x188mm 65x157mm 6mm 4x M4 @ 68x171mm .205" .110"
RT2PRO 220x166mm 64x156mm 5mm 4x M4 @ 204x146mm .205" .110"
RT8II 160x220mm 94x200mm 3.5mm 6x M4 @ 146x200mm Wire Wire
RT8M 136x219mm 94x200mm 6mm 6x M4 see drawing Wire Wire
HI-VI RESEARCH Overall Ø Cutout Ø FP Thickness Bolt Pattern Ø Connector + Type -
DMAA 145mm 102mm 5mm 6x M4 @ 130mm .205" .205"
DMBA 145mm 102mm 5mm 6x M4 @ 130mm .205" .205"
DMNA 116mm 88.5mm 3mm 6x M4 @ 102mm .250" .250"
S1 118mm 94mm 8.5mm 4x M4 @ 110mm 2x PUSH 2x PUSH
TM1A 120x175mm 60 + 91mm 3mm 6x M4 2x .205" 2x .110"
TRINITY6 173.5mm 148mm 3.5mm 4x M4 @ 166.5mm 3x PUSH 3x PUSH
D5.8 151.5mm 126.5mm 5.8mm 6x M4 @ 135mm .205" .110"
D5G 151.5mm 126.5mm 5.8mm 6x M4 @ 135mm .205" .110"
D6.8 173.5mm 135mm 5.5mm 12x M4 @ 158mm .205" .110"
D6G 173.5mm 135mm 5.5mm 12x M4 @ 158mm .205" .110"
D8.8 243mm 202mm 7.5mm 12x M5 @ 220mm .205" .110"
D8.8+ 243mm 202mm 7.5mm 12x M5 @ 220mm .205" .110"
D8G 243mm 202mm 7.5mm 12x M5 @ 220mm .205" .110"
D10.8 299mm 255mm 7mm 12x M5 @ 276mm .205" .110"
D10G 299mm 255mm 7mm 12x M5 @ 276mm .205" .110"
L5-8R 132mm 114mm 4mm 4x M4 @ 135mm .205" .110"
L6-4R 171mm 147mm 5mm 8x M4 @ 160mm .205" .110"
L6-6R 171mm 147mm 5mm 8x M4 @ 160mm .205" .110"
F5 154mm 116.5mm 5mm 6x M4 @ 137mm .205" .110"
F5BA 140mm 115mm 6.5mm 4x M4 @ 130.5mm .205" .110"
F6 197mm 149mm 5.5mm 6x M5 @ 173.5mm .205" .110"
F8 239mm 187mm 6mm 12x M5 @ 217mm .205" .110"
F10 286mm 236mm 6.5mm 12x M5 @ 263mm .205" .110"
F12 336mm 280mm 8mm 12x M5 @ 313mm .205" .110"
M5A 140mm 116mm 6mm 4x M4 @ 131mm .205" .110"
M6A 174mm 148mm 7.5mm 6x M5 @ 165mm .205" .110"
M8A 215mm 187mm 8mm 6x M5 @ 205mm .205" .110"
HI-VI RESEARCH Overall Ø Cutout Ø FP Thickness Bolt Pattern Ø Connector + Type -
M12 336mm 280mm 8mm 12x M5 @ 313mm .205" .110"
W5 153mm 115mm 5mm 6x M4 @ 136mm .205" .110"
W6 197mm 149mm 5.5mm 6x M5 @ 173.5mm .205" .110"
W10 286mm 236mm 6.5mm 12x M5 @ 263mm .205" .110"
W12 336mm 280mm 8mm 12x M5 @ 313mm .205" .110"
SP10 261mm 236mm 8mm 8x M6 @ 246mm PUSH PUSH
B1S 36x36mm 29mm 2mm 4x M3 @ 39mm .110" .110"
A2S 53x53mm 48mm 1mm 4x M3 @ 61.5mm .110" .110"
B2S 53x53mm 48mm 1mm 4x M3 @ 61.5mm .110" .110"
U2S 53x53mm 48mm 1mm 4x M3 @ 61.5mm .110" .110"
U2.5P-6 70.5x70.5mm 69mm 1mm 4x M3 @ 80mm .110" .110"
B3N 90mm 71mm 2.6mm 4x M3 @ 83mm .110" .110"
B3S 78x78mm 70mm 1mm 4x M4 @ 90mm .110" .110"
C3N-III 90mm 71mm 2.6mm 4x M3 @ 83mm .110" .110"
M3N 90mm 71mm 2.6mm 4x M3 @ 83mm .110" .110"
B4N 116.5mm 93mm 4mm 4x M4 @ 108mm .110" .110"
M4N 116.5mm 93mm 4mm 4x M4 @ 108mm .110" .110"
HI-VI RESEARCH PRO Overall Ø Cutout Ø FP Thickness Bolt Pattern Ø Connector + Type -
PA8 210mm 189mm 10.5mm 8x M5 @ 199mm PUSH PUSH
PA12 322mm 288mm 8mm 8x M6 @ 303mm PUSH PUSH
PA15 389mm 357mm 10mm 8x M6 @ 372mm PUSH PUSH
PA18 477mm 435mm 13mm 8x M6 @ 448.5mm PUSH PUSH
LCY Overall Ø Cutout Ø FP Thickness Bolt Pattern Ø Connector + Type -
LCY100K 84mm   110mm None Binding Post Binding Post
LCYK100 91mm 70mm * 5mm 4x M4 @ 77mm Wire Wire
LCY108 108x108mm 85mm* 5mm 4x M4 @ 108mm Binding Post Binding Post
LCY Overall Ø Cutout Ø FP Thickness Bolt Pattern Ø Connector + Type -
LCY110 110mm 85mm* 10mm 4x M4 @ 97mm Binding Post Binding Post
LCY130 130mm 85mm* 7.5mm 4x M4 @ 117mm Binding Post Binding Post
LPG Overall Ø Cutout Ø FP Thickness Bolt Pattern Ø Connector + Type -
20T 96mm 74mm * 2mm 4x M4 @ 84mm .110" .110"
25FA 110mm 74mm * 2mm 4x M4 @ 94mm .110" .110"
25NFA 48mm 46.5mm 2mm   .110" .110"
26NA 48mm 46.5mm 2mm   .110" .110"
26T 110mm 74mm * 2mm 4x M4 @ 94mm .110" .110"
Mark Audio Overall Ø Cutout Ø FP Thickness Bolt Pattern Ø Connector + Type -
ALPAIR5 100mm 82mm 6mm 4x M3 @ 90.4mm .205" .205"
ALPAIR6 114mm 96mm 6.2mm 4x M4 @ 104mm .205" .205"
ALPAIR6R 92x105mm 82mm * 6.2mm 4x M4 @ 80x93mm .205" .205"
CHR-70 124mm 100mm 6mm 4x M4 @ 112mm .205" .205"
ALPAIR7 135mm 103mm 8.8mm 4x M4 @ 122mm .205" .205"
ALPAIR10 160mm 137mm 9.2mm 6x M4 @ 148mm .250" .250"
ALPAIR12 207mm 169mm 11.4mm 6x M5 @ 194mm .250" .250"
MAX Fidelity Overall Ø Cutout Ø FP Thickness Bolt Pattern Ø Connector + Type -
T26AFF5NEOB 74mm 50mm 3mm 4x M4 @ 66mm .205" .110"
T26AFF5NEOBF 74mm 50mm 3mm 4x M4 @ 66mm .205" .110"
MF135/77/H4 135x135mm 123mm 6mm 4x M4 @ 141mm .205" .110"
MF135/77/L4 135x135mm 123mm 6mm 4x M4 @ 141mm .205" .110"
MF135/77/H8 135x135mm 123mm 6mm 4x M4 @ 141mm .205" .110"
MF135/77/L8 135x135mm 123mm 6mm 4x M4 @ 141mm .205" .110"
MF165/77/H4 167mm 144mm 6mm 8x M4 @ 157mm .205" .110"
MAX Fidelity Overall Ø Cutout Ø FP Thickness Bolt Pattern Ø Connector + Type -
MF165/77/L4 167mm 144mm 6mm 8x M4 @ 157mm .205" .110"
MF165/77/H8 167mm 144mm 6mm 8x M4 @ 157mm .205" .110"
MF165/77/L8 167mm 144mm 6mm 8x M4 @ 157mm .205" .110"
PR4NEO/8 103x103mm 97mm 5mm 4x M4 @ 111mm PUSH PUSH
PR65NEO 168mm 144mm 8mm 4x M5 @ 155mm .205" .205"
PR1066 261mm 238mm 10mm 8x M5 @ 247mm PUSH PUSH
PR1266         PUSH PUSH
PR1566         PUSH PUSH
PR15100         PUSH PUSH
PR15125         PUSH PUSH
PR18125         PUSH PUSH
PR21125         PUSH PUSH
PR21250         PUSH PUSH
MOREL Overall Ø Cutout Ø FP Thickness Bolt Pattern Ø Connector + Type -
MDT29 94mm 73mm 2mm 3x M3 @ 86mm .110" .110"
MDT30 94mm 73mm 2mm 3x M3 @ 86mm .110" .110"
MDT32 110mm 73mm 2.5mm 3x M4 @ 96mm .250" .250"
MDT37 94mm 73mm 3.2mm 3x M4 @ 86mm .110" .110"
MDT39 54x54mm 44mm 3mm 4x M3 @ 61mm .110" .110"
MDT40 54x54mm 44mm 3mm 4x M3 @ 61mm .110" .110"
MDM55 86x86mm 76mm * 4mm 4x M4 @ 101.5mm .250" .250"
MW144 143mm 119mm 5mm 4x M4 @ 135mm .250" .250"
MW166 160mm 138mm 5mm 4x M4 @ 152mm .250" .250"
MW168 160mm 138mm 5mm 4x M4 @ 152mm .250" .250"
CAT298 104mm 73mm * 3mm 6x M3 @ 94mm .110" .110"
CAT308 104mm 73mm * 3mm 6x M3 @ 94mm .110" .110"
CAT378 94mm 73mm 3.2mm 3x M4 @ 86mm .110" .110"
MOREL Overall Ø Cutout Ø FP Thickness Bolt Pattern Ø Connector + Type -
CAT408 72mm 44mm 3mm 6x M3 @ 59mm .110" .110"
CAW428 118.5mm 94mm 5mm 4x M3 @ 110mm .250" .250"
CAW538 143mm 124mm 5mm 6x M4 @ 135mm .250" .250"
CAW638 160mm 141mm 6mm 6x M4 @ 152mm .250" .250"
CAW938 223mm 199mm 5mm 8x M4 @ 205mm .250" .250"
ET338 110mm 76mm 3mm 6x M3 @ 100mm .250" .250"
ET338-104 104mm 76mm 3mm 6x M3 @ 94mm .250" .250"
ET448 72mm 44mm 3mm 6x M3 @ 59mm .110" .110"
EM428 118.5mm 94mm 5mm 4x M3 @ 110mm .250" .250"
EM1308 130mm 76mm 5mm 6x M3 @ 118mm .250" .250"
EW428 118.5mm 94mm 5mm 4x M3 @ 110mm .250" .250"
EW536 143mm 124mm 5mm 6x M4 @ 135mm .250" .250"
ECW536 143mm 124mm 5mm 6x M4 @ 135mm .250" .250"
EW638 160mm 141mm 6mm 6x M4 @ 152mm .250" .250"
ECW638 160mm 141mm 6mm 6x M4 @ 152mm .250" .250"
ST1048 104mm 76mm 3mm 6x M3 @ 94mm .250" .250"
ST1108 110mm 76mm 3mm 6x M3 @ 100mm .250" .250"
ST1308 130mm 104mm 5mm 6x M3 @ 118mm .250" .250"
SCM634 160mm 141mm 6mm 6x M4 @ 152mm .250" .250"
SCW636 160mm 141mm 6mm 6x M4 @ 152mm .250" .250"
HU521 143mm 124mm 5mm 6x M4 @ 135mm .250" .250"
HU531 143mm 124mm 5mm 6x M4 @ 135mm .250" .250"
HU621 160mm 141mm 6mm 6x M4 @ 152mm .250" .250"
HU9.1 223mm 199mm 5mm 8x M4 @ 205mm .250" .250"
UW958 222mm 190mm 5mm 6x M5 @ 213mm PUSH PUSH
UW1058 263mm 241mm 6.5mm 6x M5 @ 253mm PUSH PUSH
UW1258 305mm 270mm 6.3mm 6x M6 @ 292mm PUSH PUSH
PEERLESS Overall Ø Cutout Ø FP Thickness Bolt Pattern Ø Connector + Type -
104DT2608 (HDS) 104mm 79mm 4.5mm 4x M4 @ 94mm .110" .110"
A106WR2608 106x120mm 102mm 3.5mm 6x M4 @ 110mm .205" .110"
E106WR26P08 106x120mm 102mm 3.5mm 6x M4 @ 110mm .205" .110"
G106WR2608 106x120mm 102mm 3.5mm 6x M4 @ 110mm .205" .110"
N106WR26TV 106x120mm 102mm 3.5mm 6x M4 @ 110mm .205" .110"
P106WR2608 106x120mm 102mm 3.5mm 6x M4 @ 110mm .205" .110"
P106WR26TV 106x120mm 102mm 3.5mm 6x M4 @ 110mm .205" .110"
S106WR26TV 106x124mm 93mm 2.9mm 6x M4 @ 114mm .205" & .110" .205" & .110"
S106PAS32G 106x124mm 93mm 2.9mm 6x M4 @ 114mm None None
P116WR2608 116mm 94mm 3mm 4x M4 @ 107mm .205" & .110" .205" & .110"
A134WR2608 134x152mm 120mm 4mm 6x M5 @ 140mm .205" .110"
G134WR2608 134x152mm 120mm 4mm 6x M5 @ 140mm .205" .110"
N134WR2608 134x152mm 120mm 4mm 6x M5 @ 140mm .205" .110"
P134WR2608 134x152mm 120mm 4mm 6x M5 @ 140mm .205" .110"
S134WR2608 134x152mm 119mm 3.8mm 6x M4 @ 142mm .205" & .110" .205" & .110"
S134WR26TV 134x152mm 119mm 3.8mm 6x M4 @ 142mm .205" & .110" .205" & .110"
S134WR26TVP 134x152mm 119mm 3.8mm 6x M4 @ 142mm .205" & .110" .205" & .110"
S134PAS48G 134x152mm 119mm 3.8mm 6x M4 @ 142mm None None
E152WR26P08 152mm 120mm 4mm 6x M5 @ 140mm .205" .110"
A164WR3308 164x182mm 143mm 4mm 6x M5 @ 170mm .205" .110"
G164WR3308 164x182mm 143mm 4mm 6x M5 @ 170mm .205" .110"
N164WR3308 164x182mm 143mm 4mm 6x M5 @ 170mm .205" .110"
P164WR3308 164x182mm 143mm 4mm 6x M5 @ 170mm .205" .110"
S164WR2608 164x182mm 148mm 3.8mm 6x M4 @ 171mm .205" & .110" .205" & .110"
E180WR33P08 180mm 141mm 4mm 6x M5 @ 167mm .205" .110"
PEERLESS Overall Ø Cutout Ø FP Thickness Bolt Pattern Ø Connector + Type -
A205WR3808 205x225mm 190mm 4mm 6x M5 @ 201mm .205" .110"
E205WR33P08 205x225mm 190mm 4mm 6x M5 @ 201mm .205" .110"
N205WR3308 205x225mm 190mm 4mm 6x M5 @ 201mm .205" .110"
P205WR3308 205x225mm 190mm 4mm 6x M5 @ 201mm .205" .110"
S213SWR3908 213.5mm 178mm 3.5mm 8x M5 @ 204mm .205" .110"
X217WR3304 217mm 185mm 3mm 6x M4 @ 206.5mm .205" & .110" .205" & .110"
S263SWR3908 263mm 226mm 3.5mm 8x M5 @ 254mm .205" .110"
S315SWR3908 315mm 277mm 3.5mm 8x M5 @ 305mm .205" .110"
S400SWR7608 400.5mm 356mm 4.5mm 8x M6 @ 387mm .250" .250"
269SWR51XLS 269mm 240mm 5mm 8x M5 @ 251mm .205" .110"
269SWR51XXLS 269mm 240mm 5mm 8x M5 @ 251mm .205" .110"
269SWR51XXLSA 269mm 240mm 5mm 8x M5 @ 251mm .205" .110"
269SWR51XXLSB 269mm 240mm 5mm 8x M5 @ 251mm .205" .110"
269SWR51XXLSP 269mm 240mm 5mm 8x M5 @ 251mm .205" .110"
269SWR51XXLSS 269mm 240mm 5mm 8x M5 @ 251mm .205" .110"
269PAS (all) 269mm 240mm 5mm 8x M5 @ 251mm None None
308SWR51XLS 308mm 278mm 5mm 8x M5 @ 296mm .205" .110"
308SWR51XXLS 308mm 278mm 5mm 8x M5 @ 296mm .205" .110"
308SWR51XXLSA 308mm 278mm 5mm 8x M5 @ 296mm .205" .110"
308SWR51XXLSB 308mm 278mm 5mm 8x M5 @ 296mm .205" .110"
308SWR51XXLSP 308mm 278mm 5mm 8x M5 @ 296mm .205" .110"
308SWR51XXLSS 308mm 278mm 5mm 8x M5 @ 296mm .205" .110"
308PAS (all) 308mm 278mm 5mm 8x M5 @ 296mm None None
55FR2604 55x55mm 50mm 3mm 4x M3 @ 57mm .205" .110"
55FR2604B 55x55mm 50mm 3mm 4x M3 @ 57mm .205" .110"
69FR2604 69x69mm 62mm 3mm 4x M3 @ 74mm .205" .110"
69FR2608B 69x69mm 62mm 3mm 4x M3 @ 74mm .205" .110"
PEERLESS Overall Ø Cutout Ø FP Thickness Bolt Pattern Ø Connector + Type -
78FR2608 77x77mm 72mm 4mm 4x M$ @ 82mm .205" .110"
78FR2608B 77x77mm 72mm 4mm 4x M$ @ 82mm .205" .110"
CDC100C04 101mm 92mm 3mm 4x M4 @ 116mm .205" .110"
CDC130C04 130mm 115mm 3.5mm 4x M4 @ 137mm .205" .110"
CDC165C04 165.5mm 144mm 3mm 4x M4 @ 156mm .205" .110"
CDC220C04 220.5mm 185mm 5mm 4x M5 @ 210mm .205" .110"
SWR269XXLS02 269mm 240mm 5mm 8x M5 @ 251mm PUSH PUSH
SWR308XXLS02 308mm 278mm 5mm 8x M5 @ 296mm PUSH PUSH
RAAL Overall Ø Cutout Ø FP Thickness Bolt Pattern Ø Connector + Type -
70-10D 88x110mm 58x81mm 2mm 4x M5 @ 73x95mm Solder Points Solder Points
70-10DAM 88x110mm 58x81mm 2mm 4x M5 @ 73x95mm Solder Points Solder Points
70-20XR 110x110mm 65x81mm 2mm 4x M5 @ 95x95mm Solder Points Solder Points
70-20XRAM 110x110mm 65x81mm 2mm 4x M5 @ 95x95mm Solder Points Solder Points
140-15D 90x180mm 61x151mm 2mm 4x M5 @ 75x165mm Solder Points Solder Points
140-15DAM 90x180mm 61x151mm 2mm 4x M5 @ 75x165mm Solder Points Solder Points
210-10D 84x250mm 55x222mm 2mm 8x M5 @ 69x234mm Solder Points Solder Points
210-10DAM 84x250mm 55x222mm 2mm 8x M5 @ 69x234mm Solder Points Solder Points
DIPOLE140-15D 194x243mm 175x222mm 2mm 10x M5 @ see drawing Solder Points Solder Points
DIPOLE140-15DAM 194x243mm 175x222mm 2mm 10x M5 @ see drawing Solder Points Solder Points
SB ACOUSTICS Overall Ø Cutout Ø FP Thickness Bolt Pattern Ø Connector + Type -
SB25AC-C000-04 100.3mm 83mm * 3mm 4x M4 @ 88.5mm .205" .110"
SB25STNC-C000-04 72mm 47mm * 3mm 4x M4 @ 63mm .205" .110"
SB ACOUSTICS Overall Ø Cutout Ø FP Thickness Bolt Pattern Ø Connector + Type -
SB26STAC-C000-4 100.3mm 83mm * 3mm 4x M4 @ 88.5mm .205" .110"
SB29RDC-C000-04 104.3mm 70mm * 3.3mm 4x M4 @ 93mm .205" .110"
SB29RDCN-C000-04 72mm 47mm * 3mm 4x M4 @ 63mm .205" .110"
SB12NRXS25-4 123mm 95mm 6.5mm 4x M4 @ 112mm .205" .110"
SB15NRXC30-4 150mm 123mm 6.5mm 4x M4 @ 138mm .205" .110"
SB15NRXC30-8 150mm 123mm 6.5mm 4x M4 @ 138mm .205" .110"
SB17NRXC35-4 171mm 144mm 6.5mm 4x M4 @ 159mm .205" .110"
SB17NRXC35-8 171mm 144mm 6.5mm 4x M4 @ 159mm .205" .110"
SB23NRXF45-8 234mm 198mm 8.5mm 8x M4 @ 219mm .205" .110"
SB29NRX75-6 290mm 247mm 10mm 8x M5 @ 268mm Binding Post Binding Post
SB34NRX75-6 346.2mm 303mm 10mm 8x M5 @ 324.2mm Binding Post Binding Post
SB42FHC75-6 417mm 371mm 10mm 8x M5 @ 395mm Binding Post Binding Post
SW26DAC76-4 290mm 244mm 10mm 8x M5 @ 290mm .250" .250"
SW26DAC76-8 290mm 244mm 10mm 8x M5 @ 290mm .250" .250"
SCAN-SPEAK Overall Ø Cutout Ø FP Thickness Bolt Pattern Ø Connector + Type -
D2004/6020-00 55.5mm 43mm 5mm 3x M3 @ 47.6mm .110" .110"
D2008/8512 92mm 69mm 3.5mm 3x M5 @ 82mm .110" .110"
D2010/8513 98mm 69mm 5mm 4x M5 @ 86mm .110" .110"
S2010/8513 98mm 69mm 5mm 4x M5 @ 86mm .110" .110"
D2606/9200 104mm 72mm * 4.2mm 4x M4 @ 94mm .110" .110"
D2606/9220 104mm 72mm * 4.2mm 4x M4 @ 94mm .110" .110"
D2604/8300 104mm 72mm * 5mm 5x M4 @ 92mm .110" .110"
D2604/8330 104mm 72mm * 5mm 5x M4 @ 92mm .110" .110"
D2608/9130 104mm 72mm * 4.5mm 4x M4 @ 92mm .110" .110"
D2904/6100 38mm 38mm None None Wire Wire
D2904/7100 104mm 70mm * 5.9mm 6x M4 @ 92mm .205" .205"
SCAN-SPEAK Overall Ø Cutout Ø FP Thickness Bolt Pattern Ø Connector + Type -
D2904/7100-01 104mm 70mm * 5.9mm 6x M4 @ 92mm .205" .205"
D2904/9400SE 104.3mm 75mm 3.1mm 4x M5 @ 90mm .205" .205"
D2904/9800 104.5mm 75mm 3mm 4x M5 @ 90mm .110" .110"
D2905/9300 104.5mm 75mm 3mm 4x M5 @ 90mm .110" .110"
D2905/9500 104.5mm 75mm 3mm 4x M5 @ 90mm .110" .110"
D2905/9700 104.5mm 75mm 3mm 4x M5 @ 90mm .110" .110"
D2905/9900 130mm 75mm 5mm 4x M5 @ 110mm .110" .110"
D3004/6020-00 61.9mm 49m 5mm 3x M3 @ 53.9mm .110" .110"
D3004/6020-10 61.9mm 49m 5mm 3x M3 @ 53.9mm .110" .110"
D3004/6600 104mm 70mm * 5.9mm 6x M4 @ 92mm .205" .205"
D3004/6620-00 104mm 70mm * 5.9mm 3x2x M4 @ 92mm .205" .205"
D3004/6620-01 104mm 70mm * 5.9mm 3x2x M4 @ 92mm .205" .205"
D3004/6640-00 104mm 70mm * 5.9mm 6x M4 @ 92mm .205" .205"
R2004/6020-00 55.5mm 43mm 5mm 3x M3 @ 47.6mm .110" .110"
R2604/8320 104mm 72mm * 5mm 5x M4 @ 92mm .110" .110"
R2604/8330 104mm 72mm * 5mm 5x M4 @ 92mm .110" .110"
R2904/7000 104mm 70mm * 5.9mm 6x M4 @ 92mm .205" .205"
R2904/7000-09 104mm 70mm * 5.9mm 6x M4 @ 92mm .205" .205"
R3004/6020-00 61.9mm 49m 5mm 3x M3 @ 53.9mm .110" .110"
R3004/6020-10 61.9mm 49m 5mm 3x M3 @ 53.9mm .110" .110"
R3004/6620-00 104mm 70mm * 5.9mm 3x2x M4 @ 92mm .205" .205"
R3004/6620-01 104mm 70mm * 5.9mm 3x2x M4 @ 92mm .205" .205"
D3806/8200 125mm 93mm 3mm 4x M5 @ 110mm .110" .110"
D7608/9200 112.7mm 109mm 2mm None .110" .110"
D7608/920010 152mm 121mm 4mm 4x M4 @ 134mm .110" .110"
10F/4424G00 97.5mm 78mm 3.5mm 4x M3 @ 89.5mm .205" .110"
10F/8424G00 97.5mm 78mm 3.5mm 4x M3 @ 89.5mm .205" .110"
12M/4631G00 115.5mm 92mm 3mm 3x M4 @ 103mm .250" .250"
SCAN-SPEAK Overall Ø Cutout Ø FP Thickness Bolt Pattern Ø Connector + Type -
12M/4631G05 115.5mm 92mm 3mm 3x M4 @ 103mm .250" .250"
12MU/4731T00 120mm 101mm 4mm 3x2x M3 @ 111.5mm .205" .110"
12MU/8731T00 120mm 101mm 4mm 3x2x M3 @ 111.5mm .205" .110"
13M/8636 130mm 103mm 6mm 3x M3 @ 120mm .110" .110"
13M/8640 130mm 103mm 6mm 3x M3 @ 120mm .110" .110"
15M/4531K00 148mm 125mm 6.5mm 5x M5 @ 136mm .250" .250"
15M/4831G00 148mm 125mm 6.5mm 5x M5 @ 136mm .250" .250"
12W/4534G00 124.7mm 100mm 5mm 4x M5 @ 113mm .205" .110"
12W/8534G00 124.7mm 100mm 5mm 4x M5 @ 113mm .205" .110"
12WU/4731T00 120mm 101mm 4mm 3x2x M3 @ 111.5mm .205" .110"
12WU/8731T00 120mm 101mm 4mm 3x2x M3 @ 111.5mm .205" .110"
15W/4424G00 149mm 114mm 4.8mm 4x M5 @ 136.5mm .205" .110"
15W/8424G00 149mm 114mm 4.8mm 4x M5 @ 136.5mm .205" .110"
15W/4434G00 149mm 114mm 4.8mm 4x M5 @ 136.5mm .205" .110"
15W/8434G00 149mm 114mm 4.8mm 4x M5 @ 136.5mm .205" .110"
15W/4530G00 148mm 125mm 6.5mm 5x M5 @ 136mm .250" .250"
15S/8530K01 148mm 125mm 6.5mm 5x M5 @ 136mm .250" .250"
15W/8530K00 148mm 125mm 6.5mm 5x M5 @ 136mm .250" .250"
15W/8530K01 148mm 125mm 6.5mm 5x M5 @ 136mm .250" .250"
15WU/4741T00 149mm 123mm 6.5mm 3x2x M4 @ 135mm .205" .110"
15WU/8741T00 149mm 123mm 6.5mm 3x2x M4 @ 135mm .205" .110"
18W/4424G00 179.2mm 145mm 5.2mm 4x M5 @ 167mm .205" .110"
18W/8424G00 179.2mm 145mm 5.2mm 4x M5 @ 167mm .205" .110"
18W/4434G00 179.2mm 145mm 5.2mm 4x M5 @ 167mm .205" .110"
18W/8434G00 179.2mm 145mm 5.2mm 4x M5 @ 167mm .205" .110"
18W/4531G00 182mm 156mm 5.5mm 5x M5 @ 170mm .250" .250"
18S/8531G00 182mm 156mm 5.5mm 5x M5 @ 170mm .250" .250"
18W/8531G00 182mm 156mm 5.5mm 5x M5 @ 170mm .250" .250"
SCAN-SPEAK Overall Ø Cutout Ø FP Thickness Bolt Pattern Ø Connector + Type -
18W/16531G1 182mm 156mm 5.5mm 5x M5 @ 170mm .250" .250"
18S/8535 177mm 158mm 4mm 6x M3 @ 171mm .250" .250"
18W/8535 177mm 158mm 4mm 6x M3 @ 171mm .250" .250"
18W/8543 177mm 158mm 4mm 6x M3 @ 171mm .250" .250"
18W/8545 177mm 158mm 4mm 6x M3 @ 171mm .250" .250"
18W/8545K 177mm 158mm 4mm 6x M3 @ 171mm .250" .250"
18W/8546 177mm 158mm 4mm 6x M3 @ 171mm .250" .250"
18WU/4741T00 184mm 160mm 6.5mm 3x2x M4 @ 162mm .205" .110"
18WU/8741T00 184mm 160mm 6.5mm 3x2x M4 @ 162mm .205" .110"
18WU/8747T00 184mm 160mm 6.5mm 3x2x M4 @ 162mm .205" .110"
21W/8554 222mm 194mm 5.5mm 6x M5 @ 214mm .250" .250"
21W/8555 222mm 194mm 5.5mm 6x M5 @ 214mm .250" .250"
21W/8555-01 222mm 194mm 5.5mm 6x M5 @ 214mm .250" .250"
22W/4534G00 225mm 185mm 5.2mm 6x M5 @ 212mm .205" .110"
22W/8534G00 225mm 185mm 5.2mm 6x M5 @ 212mm .205" .110"
22W/4851T00 222mm 195mm 7mm 7x M5 @ 210mm .250" .250"
22W/8851T00 222mm 195mm 7mm 7x M5 @ 210mm .250" .250"
22W/8857T00 222mm 195mm 7mm 7x M5 @ 210mm .250" .250"
25W/8565-00 255mm 227mm 7mm 6x M5 @ 246.5mm .250" .250"
25W/8565-01 255mm 227mm 7mm 6x M5 @ 246.5mm .250" .250"
25W/8567SE 255mm 227mm 7mm 6x M5 @ 246.5mm .250" .250"
26W/4534G00 272mm 231mm 5.6m 6x M5 @ 258mm .205" .110"
26W/8534G00 272mm 231mm 5.6m 6x M5 @ 258mm .205" .110"
26W/4867T00 260mm 229mm 7mm 7x M5 @ 247.5mm .250" .250"
26W/8861T00 260mm 229mm 7mm 7x M5 @ 247.5mm .250" .250"
26W/8867T00 260mm 229mm 7mm 7x M5 @ 247.5mm .250" .250"
23W/4557T00 255mm 225mm 6mm 10x M5 @ 240mm Binding Post Binding Post
SCAN-SPEAK Overall Ø Cutout Ø FP Thickness Bolt Pattern Ø Connector + Type -
23W/4557T02 255mm 225mm 6mm 10x M5 @ 240mm Binding Post Binding Post
26W/4558T00 270mm 240mm 5mm 8x M5 @ 256.7mm .205" .110"
30W/4558T00 308mm 280mm 5mm 8x M5 @ 295.5mm .205" .110"
18W/0-00-01 182mm 156mm 5.5mm 5x M5 @ 170mm None None
23W/0-00-00 255mm 225mm 6mm 10x M5 @ 240mm None None
23W/0-00-02 255mm 225mm 6mm 10x M5 @ 240mm None None
26W/0-00-00 270mm 240mm 5mm 8x M5 @ 256.7mm None None
30W/0-00-00 308mm 280mm 5mm 8x M5 @ 295.5mm None None
SEAS PRESTIGE Overall Ø Cutout Ø FP Thickness Bolt Pattern Ø Connector + Type -
19TDF08 93.8mm 67mm * 3.1mm 3x M4 @ 85mm .110" .110"
20TFF08 93.8mm 67mm * 3.5mm 3x M4 @ 85mm .110" .110"
22TAF/G06 97.7mm 73mm * 3.5mm 4x M4 @ 85mm .110" .110"
25TFFN/QG06 60.5x60.5mm 45.9mm 2.1mm 4x M4 @ 58.8mm .110" .110"
26TFF06 97.7mm 73mm * 3.5mm 4x M4 @ 85mm .110" .110"
27TAF/G06 103.8mm 86mm 3.5mm 4x M4 @ 92mm .110" .110"
27TACF/G06 103.8mm 86mm 3.5mm 4x M4 @ 92mm .110" .110"
27TAFNC/D04 53mm 46mm 0.5mm 1x M4 on the back .110" .110"
27TBC/G06 103.8mm 86mm 3.5mm 4x M4 @ 92mm .110" .110"
27TBC/GTV06 103.8mm 86mm 3.5mm 4x M4 @ 92mm .110" .110"
27TBCD/GBDXT 103.8mm 86mm 6mm 4x M4 @ 92mm .110" .110"
27TDC06 103.8mm 86mm 3.5mm 4x M4 @ 92mm .110" .110"
27TDC/TV06 103.8mm 86mm 3.5mm 4x M4 @ 92mm .110" .110"
27TDFC06 103.8mm 86mm 3.5mm 4x M4 @ 92mm .110" .110"
27TDFNC/GW06 97.8mm 75mm * 3.5mm 4x M4 @ 85mm .110" .110"
27TFF06 103.8mm 86mm 3.5mm 4x M4 @ 92mm .110" .110"
27TFFC06 103.8mm 86mm 3.5mm 4x M4 @ 92mm .110" .110"
27TFFNC/G04 53mm 46mm 0.5mm 1x M4 on the back .110" .110"
SEAS PRESTIGE Overall Ø Cutout Ø FP Thickness Bolt Pattern Ø Connector + Type -
27TTFNC/GW06 97.8mm 75mm * 3.5mm 4x M4 @ 85mm .110" .110"
29TAF/W06 103.8mm 86mm 6mm 4x M4 @ 92mm .110" .110"
29TFF/W06 103.8mm 86mm 6mm 4x M4 @ 92mm .110" .110"
MCA12RC08 120.4mm 96mm 5mm 6x M5 @ 110.8mm .110" .110"
MCA15RCY08 146mm 112mm 3mm 6x M5 @ 136.5mm .205" .205"
CA12RCY08 120.4mm 96mm 5mm 6x M5 110.8mm .110" .110"
L12RCY/P08 120.4mm 96mm 5mm 4x M5 @ 111.3mm .110" .110"
CA15RLY08 146mm 112mm 4.2mm 6x M5 @ 136.5mm .205" .205"
ER15RLY08 146mm 112mm 4.2mm 6x M5 @ 136.5mm .205" .205"
L15RLY/P08 146mm 112mm 4.2mm 6x M5 @ 136.5mm .205" .205"
L16RNX04 146mm 126mm 5mm 6x M5 @ 137mm .205" .205"
L16RNX08 146mm 126mm 5mm 6x M5 @ 137mm .205" .205"
U16RCY/P08 146mm 126mm 5mm 6x M5 @ 137mm .205" .205"
CA18RLY08 176mm 146mm 5.2mm 6x M5 @ 166mm .205" .205"
CA18RNX08 176mm 146mm 5.2mm 6x M5 @ 166mm .205" .205"
ER18RNX08 176mm 146mm 5.2mm 6x M5 @ 166mm .205" .205"
G18RNX/P08 176mm 146mm 5.2mm 6x M5 @ 166mm .205" .205"
L18RNX/P08 176mm 146mm 5.2mm 6x M5 @ 166mm .205" .205"
U18RNX/P08 176mm 146mm 5.2mm 6x M5 @ 166mm .205" .205"
T18RECOAX/TV 176mm 146mm 5.2mm 6x M5 @ 166mm .110"HF .205"LF .110"HF .205"LF
T18REXFCTV2 176mm 146mm 5.2mm 6x M5 @ 166mm .110"HF .205"LF .110"HF .205"LF
SP18R 176mm 146mm 5.2mm 6x M5 @ 166mm None None
CA22RNX08 220.6mm 187mm 5.5mm 6x M5 @ 209.5mm .205" .205"
CA22RNY08 220.6mm 187mm 5.5mm 6x M5 @ 209.5mm .205" .205"
CD22RN4X08 220.6mm 187mm 5.5mm 6x M5 @ 209.5mm .205" .205"
L22RN4X/P08 220.6mm 187mm 5.5mm 6x M5 @ 209.5mm .205" .205"
FX22RCZ08 220.6mm 187mm 5.5mm 6x M5 @ 209.5mm .205" .205"
SEAS PRESTIGE Overall Ø Cutout Ø FP Thickness Bolt Pattern Ø Connector + Type -
SP22R 220.6mm 187mm 5.5mm 6x M5 @ 209.5mm None None
A26RE408 269mm 233mm 5.8mm 6x M5 @ 256mm .205" .205"
CA26RE4X08 269mm 233mm 5.8mm 6x M5 @ 256mm .205" .205"
CA26RFX08 269mm 233mm 5.8mm 6x M5 @ 256mm .205" .205"
L26RFX/P08 269mm 233mm 5.8mm 6x M5 @ 256mm .205" .205"
SP26R 269mm 233mm 5.8mm 6x M5 @ 256mm None None
SEAS DESIGN Overall Ø Cutout Ø FP Thickness Bolt Pattern Ø Connector + Type -
L26ROY04 269mm 236mm 10.5mm 8x M5 @ 256mm .250" .250"
SEAS EXCEL Overall Ø Cutout Ø FP Thickness Bolt Pattern Ø Connector + Type -
T25-001 110.4mm 85mm 6.3mm 4x M4 @ 98mm .205" .205"
T25-002 110.4mm 85mm 6.3mm 4x M4 @ 98mm .205" .205"
T25-003 110.4mm 85mm 6.3mm 4x M4 @ 98mm .205" .205"
T29AF001 110mm 85mm 5.5mm 6x M4 @ 98mm .205" .205"
T29CF001 110mm 85mm 5.5mm 6x M4 @ 98mm .205" .205"
T29CF002 110mm 85mm 5.5mm 6x M4 @ 98mm .205" .205"
T29MF001 110mm 85mm 5.5mm 6x M4 @ 98mm .205" .205"
M15CH002 146mm 112mm 4.2mm 6x M5 @ 136.5mm .205" .205"
W12CY001 120.4mm 96mm 5mm 4x M5 @ 111.3mm .110" .110"
W12CY003 120.4mm 96mm 5mm 4x M5 @ 111.3mm .110" .110"
W15CH001 146mm 112mm 4.2mm 6x M5 @ 136.5mm .205" .205"
W15CY001 146mm 112mm 4.2mm 6x M5 @ 136.5mm .205" .205"
W15LY001 146mm 112mm 4.2mm 6x M5 @ 136.5mm .205" .205"
W16NX00104 146mm 126mm 5mm 6x M5 @ 137mm .205" .205"
W16NX00108 146mm 126mm 5mm 6x M5 @ 137mm .205" .205"
W18E001 176mm 146mm 5.2mm 6x M5 @ 166mm .205" .205"
W18E001/TV 176mm 146mm 5.2mm 6x M5 @ 166mm .205" .205"
SEAS EXCEL Overall Ø Cutout Ø FP Thickness Bolt Pattern Ø Connector + Type -
W18EX001 176mm 146mm 5.2mm 6x M5 @ 166mm .205" .205"
W18NX001 176mm 146mm 5.2mm 6x M5 @ 166mm .205" .205"
W22EX001 220.6mm 187mm 5.5mm 6x M5 @ 209.5mm .205" .205"
W22NY001 220.6mm 187mm 5.5mm 6x M5 @ 209.5mm .205" .205"
W26FX001 269mm 233mm 5.8mm 6x M5 @ 256mm .205" .205"
W26FX002 269mm 233mm 5.8mm 6x M5 @ 256mm .205" .205"
C16N001/F 146mm 126mm 5mm 6x M5 @ 137mm .110"HF .205"LF .110"HF .205"LF
SEAS EXOTIC Overall Ø Cutout Ø FP Thickness Bolt Pattern Ø Connector + Type -
T3506 130mm 86mm 5.5mm 6x M4 @ 116.5mm .205" .205"
F804 220.6mm 187mm 5.5mm 6x M5 @ 209.5mm .205" .205"
F808 220.6mm 187mm 5.5mm 6x M5 @ 209.5mm .205" .205"
W808 220.6mm 187mm 5.5mm 6x M5 @ 209.5mm .205" .205"
SILVER FLUTE Overall Ø Cutout Ø FP Thickness Bolt Pattern Ø Connector + Type -
YAG20-1 88x168mm 65x157mm 3mm 6x M4 @ 77x120mm .205" .205"
W14RC2504 142mm 122mm 5mm 6x M4 @ 136mm .205" .205"
W14RC2508 142mm 122mm 5mm 6x M4 @ 136mm .205" .205"
W14RC25S04 142mm 122mm 5mm 6x M4 @ 136mm .205" .205"
W14RC25S08 142mm 122mm 5mm 6x M4 @ 136mm .205" .205"
W17RC3804 167mm 147mm 5mm 6x M4 @ 161mm .205" .205"
W17RC3808 167mm 147mm 5mm 6x M4 @ 161mm .205" .205"
W17RC38S04 167mm 147mm 5mm 6x M4 @ 161mm .205" .205"
W17RC38S08 167mm 147mm 5mm 6x M4 @ 161mm .205" .205"
W20RC3804 203mm 183mm 5mm 6x M4 @ 197mm .205" .205"
W20RC3808 203mm 183mm 5mm 6x M4 @ 197mm .205" .205"
W20RC38S08 203mm 183mm 5mm 6x M4 @ 197mm .205" .205"
TANG BAND Overall Ø Cutout Ø FP Thickness Bolt Pattern Ø Connector + Type  -
13-1761S 19.5mm 19.5mm None None Wire / .110" Wire / .110"
25-1166SJ 66mm 46mm 4mm 4x M3 @ 55.8mm .205" .110"
25-1719S 66mm 46mm 4mm 4x M3 @ 55.8mm .205" .110"
25-1744S 66mm 47mm 4mm 4x M3 @ 55.8mm .205" .110"
25-302SH 54x69.8mm 48mm 2.5mm 4x M4 @ 44x44mm .205" .110"
25-1933S 56x72mm 47mm 4mm 4x M3 @ 61.7mm .205" .110"
25-1372SC 104.3mm 86mm 2mm 3x M5 @ 90mm .205" .110"
25-1742S 110mm 87mm 5mm 6x M4 @ 98mm .205" .110"
25-1743S 110mm 87mm 5mm 6x M4 @ 98mm .205" .110"
28-847SE 72mm 48mm 4mm 4x M3 @ 62mm .205" .110"
28-1582S 110mm 84mm 4mm 3x M5 @ 96mm .205" .205"
28-537SH 110mm 84mm 4mm 3x M5 @ 96mm .205" .205"
RT-1516SA 110mm 47x77mm 5mm 4x M4 @ 96mm .205" .205"
50-1426SA 111mm 90mm 5.11mm 4x M4 @ 101mm .205" .110"
75-1558SE 140mm 117mm 5.4mm 4x M4 @ 128mm .205" .110"
W2-1767S 57x57mm 52mm 4.8mm 4x M3 @ 65.1mm .110" .110"
W4-1720 125.5mm 96mm 4.5mm 4x M5 @ 115mm .205" .110"
W4-1658SB 145mm 114mm 8.5mm 6x M5 @ 130mm .205" .205"
W5-1685 155mm 122mm 6.5mm 4x M4 @ 145mm .205" .110"
W5-704D 156.5mm 122mm 6.5mm 4x M4 @ 145mm .205" .110"
W6-1721 176.5mm 147mm 5.5mm 4x M4 @ 166.5mm .205" .110"
W6-789E 176.5mm 147mm 5.5mm 4x M4 @ 166.5mm .205" .110"
W2-1625S 58x58mm 53mm 4.5mm 4x M3 @ 68mm .205" .205"
W3-1750S 85x100mm 79x79mm 3.5mm 4x M5 @ 56x87mm .205" .205"
W46-1316E 107x159mm 96x148mm 4.5mm 4x M4 @ 90x142mm .205" .110"
W5-1138SM 155.7mm 121mm 3.6mm 4x M4 @ 145mm .205" .110"
W57-1781 132x196mm 122x185mm 5.5mm 4x M5 @ 106x170mm .205" .205"
TANG BAND Overall Ø Cutout Ø FP Thickness Bolt Pattern Ø Connector + Type -
W6-1139SI 176.5mm 142mm 4mm 4x M4 @ 166.3mm .205" .110"
W6-1936S 184.5mm 150mm 6mm 6x M4 @ 168mm .205" .110"
W69-1042J 165x233.8mm 140x210mm 4.5mm 4x M5 @ 213mm .205" .110"
W69-1436 165x233.8mm 140x210mm 4.5mm 4x M5 @ 213mm .205" .110"
W8-740P 210mm 182mm 15mm 8x M5 @ 199mm .205" .110"
W8-1747 210mm 182mm 4mm 8x M5 @ 199mm .205" .110"
W8-1747A 223.8mm 190mm 6mm 8x M5 @ 211mm .205" .110"
W8-1853 209.8mm 183mm 8.4mm 8x M5 @ 199mm .205" .110"
W8-1363SB 219mm 183mm 4.5mm 8x M5 @ 208.5mm .205" .110"
W8Q-1071F 214.8x308mm 191x279mm 5mm 4x M5 @ 201.3x202.3mm .205" .110"
WT-1427B 262.5mm 233mm 6mm 8x M5 @ 245mm .205" .110"
WQ-1814S 312mm 278mm 6mm 8x M5 @ 299mm .205" .110"
WQ-1858 312mm 280mm 10mm 8x M6 @ 296.5mm Binding Post Binding Post
W1-1925S 25mm 22.7mm 2.3mm None Wire Wire
W1-1815S 31mm 28.8mm 2.3mm None Wire Wire
W1-1070SE 43x43mm 37.6mm 2.5mm 4x M4 @ 34x34mm .110" .110"
W1-1828S 46mm 42.4mm 2.3mm None Wire Wire
W2-748SG 57mm 51.7mm 4.3mm None .110" .110"
W2-800SL 57x57mm 51.7mm 4.3mm 4x M3 @ 65.1mm .110" .110"
W2-803SM 57x57mm 51.7mm 4.3mm 4x M3 @ 65.1mm .110" .110"
W2-852SH 57x57mm 51.7mm 4.3mm 4x M3 @ 65.1mm .110" .110"
W2-1803S 57x57mm 51.9mm 3.5mm 4x M3 @ 65.1mm .205" .110"
W2-1811S 57x57mm 51.7mm 4.3mm 4x M3 @ 65.1mm .110" .110"
W23-1287SI 52.8x92mm 47.5x86.5mm 3.5mm 4x M4 @ 42x82mm .205" .110"
W3-593SF 81x81mm 78.5mm 0.6mm 4x M4 @ 84.4mm .205" .110"
W3-926SD 81x81mm 76.5mm 0.7mm 4x M4 @ 84.2mm .205" .110"
W3-1053SC 81x81mm 78.5mm 0.6mm 4x M4 @ 84.4mm .205" .110"
TANG BAND Overall Ø Cutout Ø FP Thickness Bolt Pattern Ø Connector + Type -
W3-315E 93mm 76mm 3.5mm 4x M4 @ 85mm .205" .110"
W3-319SF 93mm 76mm 3.5mm 4x M4 @ 85mm .205" .110"
W3-881SJ 93mm 76mm 3.5mm 4x M4 @ 85mm .205" .110"
W3-1335SB 93mm 76mm 3.5mm 4x M4 @ 85mm .205" .110"
W3-1364SA 93mm 76mm 3.5mm 4x M4 @ 85mm .205" .110"
W3-1401SD 81x93mm 76mm 3.5mm 4x M4 @ 85mm .205" .110"
W3-1797S 93mm 74mm 4.5mm 4x M4 @ 85mm .205" .205"
W3-1878 93mm 76mm 3.5mm 4x M4 @ 85mm .205" .110"
W4-616SA 106x106mm 102mm 3mm 4x M5 @ 115mm .205" .110"
W4-1052SD 116mm 93mm 3mm 4x M4 @ 108mm .205" .110"
W4-1320SJ 108.1x125.5mm 96m 4.5mm 4x M5 @ 115mm .205" .110"
W4-1337SD 125.5mm 96m 4.5mm 4x M5 @ 115mm .205" .110"
W4-1757S 108.1x125.5mm 96m 4mm 4x M5 @ 115mm .205" .110"
W4-1757SB 108.1x125.5mm 96m 5mm 4x M5 @ 115mm .205" .110"
W4-656SC 125.5mm 96m 4.5mm 4x M5 @ 115mm .205" .110"
W4-657SH 125.5mm 96m 4.5mm 4x M5 @ 115mm .205" .110"
W4-1879 125.5mm 96m 4.5mm 4x M5 @ 115mm .205" .110"
W4-1798S 145mm 114mm 8.5mm 6x M5 @ 130mm .205" .110"
W5-1611SA 157mm 131mm 5.8mm 4x M5 @ 145mm .205" .110"
W5-1880 155mm 122mm 6mm 4x M5 @ 145mm .205" .110"
W6-1914S 178.8mm 148mm 8.3mm 6x M5 @ 162mm .205" .110"
W6-1916 176.5mm 147mm 5.5mm 4x M4 @ 166.5mm .205" .110"
W8-1772 223.8mm 190mm 6mm 8x M5 @ 211mm .205" .110"
W8-1808 223.8mm 190mm 6mm 8x M5 @ 211mm .205" .110"
W3-1723SA 93mm 79mm 3mm 4x M4 @ 84.5mm .110"HF .205"LF .110"HF .110"LF
TYMPHANY LAT Overall Ø Cutout Ø FP Thickness Bolt Pattern Ø Connector + Type -
LAT250-02 258.5x89.1mm 240x70mm 5mm 30x M3 2x .205" 2x .110"
LAT500-04 407x179.5mm 378x150mm 5mm 24x M4 2x PUSH 2x PUSH
LAT500-08 407x179.5mm 378x150mm 5mm 24x M4 2x PUSH 2x PUSH
LAT700-04 481x218mm 451x190mm 5mm 24x M5 2x PUSH 2x PUSH
LAT700-08 481x218mm 451x190mm 5mm 24x M5 2x PUSH 2x PUSH
VERAVOX Overall Ø Cutout Ø FP Thickness Bolt Pattern Ø Connector + Type -
VERAVOX3X 79mm 69mm 3mm None .205" .110"
VERAVOX5S 136x136mm 114mm 4mm 4x M5 @ 139mm .250" .250"
VERAVOX7X 183x204mm 165mm 5.1mm 6x M4 @ 192mm .250" .250"
VIFA Overall Ø Cutout Ø FP Thickness Bolt Pattern Ø Connector + Type -
D19SD0508 94.3mm 72mm 3mm 3x M4 @ 85mm .110" .110"
D19TD0508 94.3mm 68mm * 3mm 3x M4 @ 85mm .110" .110"
DX19SD0504 94.3mm 68mm * 4mm 4x M4 @ 80mm .110" .110"
DX19TD0504 94.3mm 68mm * 4mm 4x M4 @ 80mm .110" .110"
XT19SD0004 94.3mm 68mm * 4mm 4x M4 @ 80mm .110" .110"
XT19TD0004 94.3mm 68mm * 4mm 4x M4 @ 80mm .110" .110"
NE19VTA04 52mm 40mm 5.5mm 3x M3 @ 43mm .110" .110"
NE19VTC04 52mm 40mm 5.5mm 3x M3 @ 43mm .110" .110"
NE19VTS04 52mm 40mm 5.5mm 3x M3 @ 43mm .110" .110"
NE19VTT04 52mm 40mm 5.5mm 3x M3 @ 43mm .110" .110"
BC25TG1504 104mm 70mm * 4.2mm 4x M4 @ 92mm .110" .110"
D25AC0506 45.1mm 45.1mm None None .110" .110"
D25AG0506 104mm 75mm * 4mm 4x M4 @ 94mm .110" .110"
D25AG3506 104mm 75mm * 4mm 4x M4 @ 94mm .110" .110"
VIFA Overall Ø Cutout Ø FP Thickness Bolt Pattern Ø Connector + Type -
D25ASG0506 104mm 80mm * 4mm 4x M4 @ 94mm .110" .110"
DX25SG0504 104mm 75mm * 5mm 5x M4 @ 91mm .110" .110"
DX25TG0504 104mm 75mm * 5mm 5x M4 @ 91mm .110" .110"
DX25TG0904 104mm 75mm * 5mm 5x M4 @ 91mm .110" .110"
XT25BG6004 104mm 75mm * 5mm 5x M4 @ 91mm .110" .110"
XT25SC3004 104mm 75mm * 5mm 5x M4 @ 91mm .110" .110"
XT25SC5004 64mm 45mm 4mm 3x M4 @ 52mm .110" .110"
XT25SC9004 64mm 45mm 4mm 3x M4 @ 52mm .110" .110"
XT25TG3004 104mm 75mm * 5mm 5x M4 @ 91mm .110" .110"
NE25VTA04 66mm 48mm 5.5mm 3x M4 @ 55mm .110" .110"
NE25VTC04 66mm 48mm 5.5mm 3x M4 @ 55mm .110" .110"
NE25VTS04 66mm 48mm 5.5mm 3x M4 @ 55mm .110" .110"
NE25VTT04 66mm 48mm 5.5mm 3x M4 @ 55mm .110" .110"
D26NC0506 45.1mm 45.1mm None None .110" .110"
D26NC5506 53.5x70mm 49.2mm 4mm 4x M4 @ 66mm .110" .110"
D26TG0506 104mm 75mm * 4mm 4x M4 @ 94mm .110" .110"
D26TG3506 104mm 75mm * 4mm 4x M4 @ 94mm .110" .110"
H26TG0506 104mm 75mm * 4mm 4x M4 @ 94mm .110" .110"
H26TG3506 104mm 75mm * 4mm 4x M4 @ 94mm .110" .110"
D27SG1506 104mm 80mm * 4mm 5x M4 @ 94mm .110" .110"
D27TG0506 104mm 75mm * 4mm 4x M4 @ 94mm .110" .110"
D27TG1506 104mm 75mm * 4mm 5x M4 @ 94mm .110" .110"
D27TG3506 104mm 75mm * 4mm 4x M4 @ 94mm .110" .110"
D27TG4506 104mm 75mm * 4mm 5x M4 @ 94mm .110" .110"
NE65W04 65.14mm 47mm 5.5mm 3x M3 @ 58.2mm .110" .110"
S09FD0208 88.1mm 78.3mm 4.1mm 4x M4 @ 95.2mm .110" .110"
TG9FD1004 84x84mm 78mm 3.2mm 4x M4 @ 89.5mm .110" .110"
VIFA Overall Ø Cutout Ø FP Thickness Bolt Pattern Ø Connector + Type -
TG9FSD1004 84x84mm 78mm 3.2mm 4x M4 @ 89.5mm .110" .110"
NE85W04 85mm 58mm 5mm 3x M3 @ 76mm .110" .110"
NE95W04 95.14mm 65mm 5mm 3x M3 @ 85mm .110" .110"
M10MD3908 104mm 81.2mm 4mm 4x M5 @ 95mm .110" .110"
NE123W04 123mm 94mm 4mm 5x M4 @ 111mm .110" .110"
M13SG0908 140mm 115mm 4mm 4x M5 @ 132mm .205" & .110" .205" & .110"
NE149W04 149mm 116mm 7.5mm 5x M4 @ 137mm .110" .110"
P17SJ0008 170mm 146mm 4.2mm 4x M5 @ 162mm .205" & .110" .205" & .110"
P17WJ0008 170mm 146mm 4.2mm 4x M5 @ 162mm .205" & .110" .205" & .110"
NE180W04 180mm 145mm 8.5mm 5x M4 @ 168mm .110" .110"
MG22W00908 225mm 186mm 5mm 6x M5 @ 213mm .205" & .110" .205" & .110"
NE225W04 225mm 182mm 8.5mm 5x M4 @ 212mm .110" .110"
NE265W04 265mm 236mm 10.5mm 5x M5 @ 250mm .110" .110"
NE315W04 315mm 284mm 10.5mm 5x M5 @ 300mm .110" .110"
VIFA premium Overall Ø Cutout Ø FP Thickness Bolt Pattern Ø Connector + Type -
PL11WG0904 125mm 101mm 5mm 4x M5 @ 113mm .205" & .110" .205" & .110"
PL11WH0904 125mm 101mm 5mm 4x M5 @ 113mm .205" & .110" .205" & .110"
PL14WJ0908 149mm 115mm 4.5mm 4x M5 @ 131mm .205" & .110" .205" & .110"
PL14WJ0904 149mm 115mm 4.5mm 4x M5 @ 131mm .205" & .110" .205" & .110"
PL18W00908 180mm 146mm 5mm 6x M5 @ 167mm .205" & .110" .205" & .110"
PL18W00904 180mm 146mm 5mm 6x M5 @ 167mm .205" & .110" .205" & .110"
PL22WR0904 225mm 186mm 5mm 6x M5 @ 213mm .205" & .110" .205" & .110"
VISATON Overall Ø Cutout Ø FP Thickness Bolt Pattern Ø Connector + Type -
MHT12 112mm 94mm 5mm 4x M5 @ 120mm .205" .110"
TL16H 84mm None None None Push Push
G20SC 94mm 64mm * 2mm 4x M4 @ 82mm .205" .110"
DSM25FFL 96x96mm 70mm * 2mm 4x M5 @ 110mm .205" .110"
G25FFL 104mm 76mm * 2mm 4x M4 @ 94mm .205" .110"
G25ND 104x51mm 45mm * 2mm 2x M4 @ 70mm .205" .110"
KE25SC 104.5mm 80mm 5mm 4x M4 @ 94mm .205" .110"
SC4ND 50mm       Wire Wire
SC10NC 104mm 82mm 2.5mm 4x M4 @ 94mm .205" .110"
DSM50FFL 130x130mm 100mm * 2mm 4x M4 @ 126mm .205" .110"
G50FFL 140mm 100mm * 2.5mm 4x M4 @ 126mm .205" .110"
TI100 122mm 100mm 4mm 4x M4 @ 111mm .205" .110"
W100SC 122mm 94mm 6mm 5x M3 @ 111mm .205" .110"
AL130M 153mm 114mm 4.5mm 4x M4 @ 141mm .205" .110"
AL130 153mm 114mm 4.5mm 4x M4 @ 141mm .205" .110"
W130SC 146mm 108mm 6mm 5x M4 @ 135mm .205" .110"
AL170 180mm 148mm 5mm 4x M4 @ 168mm .205" .110"
W170SC 187mm 147mm 7mm 5x M4 @ 175mm .205" .110"
WS17E 166mm 146mm 1mm 4x M5 @ 175mm .205" .110"
B200 222mm 189mm 6mm 6x M5 @ 210mm .205" .110"
GF200 222mm 189mm 6mm 6x M5 @ 210mm .205" .110"
AL200 222mm 189mm 6mm 6x M5 @ 210mm .205" .110"
TIW200XS 222mm 189mm 6mm 6x M5 @ 210mm PUSH PUSH
W200SC 232mm 182mm 7mm 5x M5 @ 218mm .205" .110"
B200 222mm 189mm 6mm 6x M5 @ 210mm .205" .110"
TIW250XS 276mm 234mm 6.2mm 6x M5 @ 264mm PUSH PUSH
TIW300 329mm 287mm 6mm 8x M6 @ 312.5mm PUSH PUSH
BGS40 403mm 359mm 10mm 8x M6 @ 382mm PUSH PUSH
VISATON (Industrial) Overall Ø Cutout Ø FP Thickness Bolt Pattern Ø Connector + Type -
K20.40 20x40mm 18x38mm 3mm 4x M2 @ 16x36mm .110" .110"
SC4.7ND 41x71mm 35x65mm 1mm 4x M3 @ 33.5x63.5mm .110" .110"
SC5.9ND 50.5x90.5mm 43x82mm 2.5mm 4x M4 @ 40.5x76mm .110" .110"
SC5.9 50.5x90.5mm 43x82mm 4mm 4x M4 @ 40x75mm .110" .110"
SL713 75x130mm 63x118mm 5mm 4x M5 @ 52x107mm .110" .110"
FR9.15 95x155mm 87x146mm 5mm 4x M4 @ 74x123mm .110" .110"
FRS5 52.5mm 46mm 1mm 2x M4 @ 60mm .110" .110"
FRWS5 50x50mm 45mm 3.5mm 4x M3 @ 62.8mm .110" .110"
FRWS5R 50mm 45mm 3.5mm None .110" .110"
FRWS5SC 50x50mm 45mm 3.5mm 4x M3 @ 62.8mm .110" .110"
K50 50mm 45mm 2.2mm None .110" .110"
K50SQ 51x51mm 45mm 4.2mm 4x M4 @ 40x40mm .110" .110"
FRS7 66.5x66.5mm 61mm 3mm 4x M4 @ 75mm .110" .110"
FRS7S 66.5x66.5mm 61mm 3mm 4x M4 @ 75mm .110" .110"
FRS7W 66.5x66.5mm 61mm 3mm 4x M4 @ 75mm .110" .110"
FR8 80x80mm 75mm 3mm 4x M4 @ 86mm .205" .110"
FRS8 78.5x78.5mm 72mm 4mm 4x M4 @ 84mm .205" .110"
FRS8M 78x78mm 77mm 2.3mm 4x M4 @ 93mm .205" .110"
F8SC 78.5x78.5mm 76mm 4.5mm 4x M4 @ 83mm .205" .110"
SC8 77.5x77.5mm * 73mm 5.7mm 4x M3 @ 90mm .205" .110"
SC8N 77.5x77.5mm * 73mm 5.7mm 4x M3 @ 90mm .205" .110"
FR87 84.5x84.5mm 80mm 4mm 4x M5 @ 98mm .205" .110"
FR10 105x105mm 100mm 3mm 4x M5 @ 115mm .205" .110"
FR10F 101.5mm 94mm 4mm 2x M5 @ 115.5mm .205" .110"
FR10HM 100mm 94mm 3mm 4x M4 @ 116.5mm .205" .110"
R10S 102x102mm 93mm 4mm 4x M5 @ 117mm .205" .110"
R10SC 102x102mm 93mm 4mm 4x M5 @ 117mm .205" .110"
FR12 130mm 114mm 3mm 4x M4 @ 135mm .205" .110"
VISATON (Industrial) Overall Ø Cutout Ø FP Thickness Bolt Pattern Ø Connector + Type -
FR13 129mm 116mm 4mm 4x M5 @ 139mm .205" .110"
FR6,5 171mm 143mm 9mm 4x M4 @ 156mm .205" .110"
VISATON (Water Resistant) Overall Ø Cutout Ø FP Thickness Bolt Pattern Ø Connector + Type -
K28WP 28mm 28mm None None Solder Points Solder Points
K36WP 36mm 36mm None None Solder Points Solder Points
K50WP 50mm 46mm 2.5mm None .110" .110"
K64WP 64mm 60mm 3mm None .110" .110"
K64WPT 64mm 60mm 3mm None .110" .110"
SL87WPM 83x83mm 80mm 3mm 4x M5 @ 100mm .110" .110"
SL87XA 83x83mm 80mm 3mm 4x M5 @ 100mm .110" .110"
FR8WP 90mm 74mm 12mm 4x M3 @ 82.5mm .205" .110"
FR10WP 132mm 101mm 15mm 4x M4 @ 120mm .205" .110"
FRS10WP 115x115mm 92mm 6mm 4x M4 @ 133mm .205" .110"
FR13WP 150mm 112mm 15mm 4x M4 @ 136mm .205" .110"
FR16WP 180mm 142mm 17mm 4x M4 @ 167mm .205" .110"
VOLT Overall Ø Cutout Ø FP Thickness Bolt Pattern Ø Connector + Type -
VM752 190mm 154mm 22mm 4x M6 @ 172mm .205" .205"
BM220.808 223x223mm 192mm 9mm 4x M5 @ 218mm .205" .205"
B220.208 223x223mm 192mm 9mm 4x M5 @ 218mm .205" .205"
DVC220.108 223x223mm 192mm 9mm 4x M5 @ 218mm .205" .205"
B250.808 262x262mm 245mm 8mm 4x M5 @ 268mm .205" .205"
B2500.108 262x262mm 245mm 8mm 4x M5 @ 268mm PUSH PUSH
BM2500.408 262x262mm 245mm 8mm 4x M5 @ 268mm PUSH PUSH
RV314308 310mm 280mm 13mm 8x M6 @ 294mm PUSH PUSH
RV386308 380mm 357mm 13mm 8x M6 @ 370mm PUSH PUSH
VOLT Overall Ø Cutout Ø FP Thickness Bolt Pattern Ø Connector + Type -
R450408 459mm 398mm 13mm 8x M8 @ 440mm PUSH PUSH
DVC2517 262x262mm 245mm 8mm 4x M5 @ 268mm PUSH PUSH
VOXATIV Overall Ø Cutout Ø FP Thickness Bolt Pattern Ø Connector + Type -
AC-1 202mm 190mm 10mm 4x M6 @ 207mm Binding Post Binding Post
AC-2 202mm 190mm 10mm 4x M6 @ 207mm Binding Post Binding Post
AC-2A 202mm 190mm 10mm 4x M6 @ 207mm Binding Post Binding Post
AC-2B 202mm 190mm 10mm 4x M6 @ 207mm Binding Post Binding Post
AC-2.5 202mm 190mm 10mm 4x M6 @ 207mm Binding Post Binding Post
AC-3 202mm 190mm 10mm 4x M6 @ 207mm Binding Post Binding Post
AC-3B 202mm 190mm 10mm 4x M6 @ 207mm Binding Post Binding Post
AC-X 202mm 190mm 10mm 4x M6 @ 207mm Binding Post Binding Post
WAVECOR Overall Ø Cutout Ø FP Thickness Bolt Pattern Ø Connector + Type -
TW022WA01 39.6mm 39.6mm None None .205" .110"
TW022WA02 65mm 39.6mm 4.2mm 3x M4 @ 53mm .205" .110"
TW022WA03 39.6mm 39.6mm None None .205" .110"
TW022WA04 65mm 39.6mm 4.2mm 3x M4 @ 53mm .205" .110"
TW030WA01 76mm 56mm 5mm 4x M4 @ 66mm .205" .110"
TW030WA02 76mm 56mm 5mm 4x M4 @ 66mm .205" .110"
TW030WA03 51.5mm 51.5mm None None .205" .110"
TW030WA04 51.5mm 51.5mm None None .205" .110"
TW030WA05 115mm 93mm 4mm 4x M4 @ 105mm .205" .110"
TW030WA06 115mm 93mm 4mm 4x M4 @ 105mm .205" .110"
TW030WA07 115mm 93mm 4mm 4x M4 @ 105mm .205" .110"
WAVECOR Overall Ø Cutout Ø FP Thickness Bolt Pattern Ø Connector + Type -
TW030WA08 115mm 93mm 4mm 4x M4 @ 105mm .205" .110"
WF120BD01 120mm 99mm 5mm 4x M5 @ 110mm .205" .110"
WF120BD02 120mm 99mm 5mm 4x M5 @ 110mm .205" .110"
WF120BD03 120mm 99mm 5mm 4x M5 @ 110mm .205" .110"
WF120BD04 120mm 99mm 5mm 4x M5 @ 110mm .205" .110"
WF152BD01 152mm 128mm 5.5mm 4x M5 @ 140mm .205" .110"
WF152BD02 152mm 128mm 5.5mm 4x M5 @ 140mm .205" .110"
WF152BD03 152mm 128mm 5.5mm 4x M5 @ 140mm .205" .110"
WF152BD04 152mm 128mm 5.5mm 4x M5 @ 140mm .205" .110"
WF182BD01 182mm 153mm 6mm 6x M5 @ 169.5mm .205" .110"
WF182BD02 182mm 153mm 6mm 6x M5 @ 169.5mm .205" .110"
WF182BD03 182mm 153mm 6mm 6x M5 @ 169.5mm .205" .110"
WF182BD04 182mm 153mm 6mm 6x M5 @ 169.5mm .205" .110"
SW070WA01 70x70mm 62.5mm 4mm 4x M4 @ 51.6x51.6mm .205" .110"
SW070WA02 70x70mm 62.5mm 4mm 4x M4 @ 51.6x51.6mm .205" .110"
SW182BD01 182mm 153mm 6mm 6x M5 @ 169.5mm .205" .110"
SW182BD02 182mm 153mm 6mm 6x M5 @ 169.5mm .205" .110"
SW223BD01 223.5mm 191mm 6mm 6x M5 @ 210mm .205" .110"
SW263WA01 263mm 234mm 9.5mm 8x M5 @ 247mm PUSH PUSH
SW263WA03 263mm 234mm 9.5mm 8x M5 @ 247mm PUSH PUSH
SW310WA01 312mm 281mm 9.3mm 8x M5 @ 297.3mm PUSH PUSH
SW310WA02 312mm 281mm 9.3mm 8x M5 @ 297.3mm PUSH PUSH
FR070WA01 70x70mm 62.5mm 4mm 4x M4 @ 51.6x51.6mm .205" .110"
FR070WA02 70x70mm 62.5mm 4mm 4x M4 @ 51.6x51.6mm .205" .110"
PR182BD01 182mm 153mm 6mm 6x M5 @ 169.5mm None None
PR223BD01 223.5mm 191mm 6mm 6x M5 @ 210mm None None
PR263WA01 263mm 234mm 9.5mm 8x M5 @ 247mm None None
PR310WA01 312mm 281mm 9.3mm 8x M5 @ 297.3mm None None
ZR SPEAKER LABS Overall Ø Cutout Ø FP Thickness Bolt Pattern Ø Connector + Type -
ZR25T 50mm 44mm   3x M3 @
ZR25N 50mm 44mm   None
ZR25C 110mm 81mm   6x M3 @
ZRSATURN 70mm 65mm   None
ZR12M 120mm 101mm   6x M4 @ .250 .250
ZRno1 166mm 146mm   4x M4 @ .250 .250
ZR17MW 170mm 147mm   4x M4 @ .250 .250
ZR18DD 180mm 157mm   6x M4 @ Binding Post Binding Post
ZR18W 180mm 157mm   6x M4 @ Binding Post Binding Post

[/vc_column_text][/vc_column][/vc_row]

Nous utilisons des cookies pour vous offrir la meilleure expérience de navigation sur notre site. Politique de confidentialité.
