10CMV2

Name: 10CMV2
Brand: BEYMA
SKU: 10CMV2
Price: 110.72 CAD
Availability: OutOfStock

(0)

Out of stock

Beyma 10CMV2, 25.8cm (10.25in / 10-1/4in) Paper Cone Pro Midbass, with 38mm Voice Coil, 95dB, 8ohm.

CA$110.72^Each

Pro Bass Midranges

Choose another model

Choose another model
PD.153C01 CA$310.00 ^Each CA$420.00
ROSSO-6MW150D CA$127.68^Each
BIANCO-8MW125 CA$83.23^Each
BIANCO-8MWN150 CA$99.00 ^Each CA$165.88
BIANCO-10MW150 CA$110.18^Each
BIANCO-10MW200 CA$109.73^Each
BIANCO-12MW200 CA$127.90^Each
ROSSO-12MW300 CA$209.50^Each
BIANCO-12OB150 CA$110.95^Each
NERO-12MWN400D CA$313.45^Each
BIANCO-15MW200 CA$136.23^Each
BIANCO-15MW350 CA$189.63^Each
BIANCO-15OB350 CA$187.40^Each
ROSSO-15MW500 CA$301.90^Each
MB620-8 CA$68.08^Each
MB820-8 CA$63.59^Each
MB1025-8 CA$84.79^Each
6MB200N-8 CA$199.28^Each
8MB200N-8 CA$218.42^Each
10MB250N-8 CA$206.98^Each
12MB400N-8 CA$329.58^Each
15MB500N-8 CA$276.16^Each
WF259PA01 CA$551.68^Each
WF259PA02 CA$551.68^Each
5MP60/N CA$96.46^Each
6B30/P CA$85.50^Each
8BR40/N CA$99.76^Each
WF211PA01 CA$342.61^Each
WF211PA02 CA$342.61^Each
NERO-10MWN600D CA$313.45^Each
NERO-12MWN700D CA$332.08^Each
NERO-15MWN700D CA$370.73^Each
6PT-8 CA$26.76^Each
8PT-8 CA$37.79^Each
BIANCO-8MW250 CA$84.68^Each
NERO-8MWN400D CA$248.23^Each
PAW25 CA$208.32^Each
PAW30ND CA$557.57^Each
6CMV2 CA$86.60^Each
8CMV2 CA$95.36^Each
12CMV2 CA$160.60^Each
15CMV2 CA$210.47^Each
5G40ND/N CA$188.55^Each
6G40ND CA$226.91^Each
8G40 CA$185.26^Each
8MC300ND CA$316.80^Each
8MC500ND CA$356.27^Each
10MCS500 CA$237.87^Each
10MCB700 CA$314.60^Each
10MC700ND CA$488.90^Each
10MC500 CA$265.28^Each
12MCS500 CA$249.93^Each
12MCB700 CA$321.19^Each
12MC700ND CA$502.06^Each
12MC500 CA$279.54^Each
15MC500 CA$317.90^Each
15MC700ND CA$556.87^Each
15MCB700 CA$384.80^Each
5P200FE CA$124.97^Each
5P200ND CA$208.28^Each

Quantity

SKU: 10CMV2
Brand: BEYMA

Beyma 10CMV2, 25.8cm (10.25in / 10-1/4in) Paper Cone Pro Midbass, with 38mm Voice Coil, 95dB, 8ohm.

Technical specifications

Power capacity

250 W AES

Nominal diameter

250 mm 10 in

Nominal impedance

8 Ohm

Minimum impedance

7.2 ohm

Program power

500 W

Sensitivity

95 dB 1 W/1 m @ ZN

Frequency range

60-5000 Hz

Recommended enclosure volume

30 l

Voice coil diameter

38.1 mm 1.5 in

BL factor

13.4 N/A

Moving mass

0.042 kg

Winding length

16 mm

Air gap height

7 mm

Xdamage pp

30 mm

Parameters Thiele & Small

52 Hz

5.9 ohm

Qms

3.8

Qes

0.47

Qts

0.42

Vas

44 l

Cms

216 µm / N

Rms

3.7 kg / s

Efficiency %

1.3

0.038 m²

Xmax

6.5 mm

247 cm³

Le @1 kHz

0.8 mH

Construction details

Depth

115 mm 4.52 in

Net weight

3.1 kg 6.82 lb

Total weight

3.5 kg 7.77 lb

Magnet

Ferrite

FILENAME	ACTION
10CMV2.pdf	Download
