TW030WA23
28 left in stock
WAVECOR TW030WA23, 30mm (1.25in / 1-1/4in) Tetoron Graphene Dome Neodymium Tweeter, 4ohm, 76mm Faceplate
CA$143.50Each
- TW030WA23
- WAVECOR
WAVECOR TW030WA23, 30mm (1.25in / 1-1/4in) Tetoron Graphene Dome Neodymium Tweeter, 4ohm, 76mm Faceplate
The TW030WA23 is a true high-end tweeter designed for the most demanding applications featuring an array of performance improving details that participate in obtaining low resonance frequency, low distortion and extended frequency response.
FEATURES:
- Graphene reinforced textile dome with increased high-frequency extension, consistency, and temperature rating
- 30 mm voice coil design with high power handling, and low resonance frequency
- Copper clad center pole yielding very low voice coil inductance for reduced distortion and increased high frequency output
- Vented through to a damped rear chamber for low resonance frequency and low distortion
- Rear heat sink for increased long term power handling
- Vented voice coil former for reduced distortion and compression
- Copper-clad aluminium voice coil wire offering lower moving mass for improved efficiency and transient response
- Built-in cavities under dome/edge to equalize pressure - for lower distortion and lower resonance frequency
- Flexible lead wires for higher power handling and larger excursion
- Gold plated terminals to prevent oxidation and ensure long-term reliable connection
- Delivered with foam gasket attached for hassle-free mounting and secure cabinet sealing
| FILENAME | ACTION |
|---|---|
| TW030WA23_24_25_26.pdf | Download |
