BM165.108
- BM165.108
- VOLT
Volt Loudspeakers BM165.1, 189mm (7.5in / 7-1/2in) Hips Polypropylene Cone Mid-Bass, with 38mm Voice Coil, 88db, 8ohm.
| Product Specifications | |
|---|---|
| Manufacturer | VOLT |
| Speaker Type | Hips Cone Mid-Bass |
| Nominal Diameter | 17cm |
| Impedance | 8 ohms |
| Power Handling (RMS) | 100 W |
| Frequency Response | 50 - 3000 Hz |
| Sensitivity | 88 dB |
| Voice Coil Diameter | 38mm |
The BM165.1 (6.5") is a critically doped plastic HIPS cone drive unit, developed for bass/mid applications that require minimal colouration and low distortion over a wide frequency range. It uses a symmetrical field magnet system with an extended pole piece for large linear excursion capability, along with mirrored double rear suspensions that guarantee transient stability at high drive levels. The Thiele-Small parameters are optimised for relatively small enclosures to give a bass performance that complements the extended midband enabling excellent 2-way systems. The diecast aluminium chassis is vented below the suspensions to increase cooling airflow to the voice coil.
| FILENAME | ACTION |
|---|---|
| bm1651.pdf | Download |
